Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
8
HDMI Input Signal Timing:
Supported
Resolution
H(KHZ) V(HZ) Standard
EDID
Assignment
Panel Type
NOTE2
H×V
1366X768 1920X1080
640×480
31.5 60 VESA DMT
Established
Timings
YES
YES
720×400
31.5 70 VESA DMT
Established
Timings
YES
YES
800×600
37.9 60 VESA DMT
Established
Timings
YES
YES
800×600
35.1 56 VESA
Established
Timings
YES
YES
1024×768
48.4 60 VESA DMT
Established
Timings
YES
YES
1280×768
47.4 60 VESA DMT
Detailed Timing
Description 2
YES
YES NOTE3
1280×720
45 60 VESA DMT
Standard Timing
Identification
YES
YES 16:9
1280×800
49.7 60 VESA DMT
Standard Timing
Identification
YES
YES 16:10
1280×800
62.8 75 VESA DMT
Standard Timing
Identification
YES
YES
16:10
Mandatory
1280×960
60 60 VESA DMT
Standard Timing
Identification
YES
YES 4:3
1280×1024
64 60 VESA DMT
Standard Timing
Identification
YES
YES 5:4
1440×900
55.9 60 VESA DMT
Standard Timing
Identification
YES
YES 16:10
1680×1050
65.3 60 VESA DMT
Standard Timing
Identification
NOTE1
YES
16:10
Mandatory
1920×1080
67.5 60 CEA-861
Detailed Timing
Description 1
YES
YES NOTE3

Sharp LC-42LB261U Specifications

General

Brand	Sharp
Model	LC-42LB261U
Category	LED TV
Language	English
