Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
86
BOM List
Customer Model LC-32LB261U
TPV Model E32E41NKFMBSNNX
LOCATION PART NO. DESCRIPTION
PANEL LCA315HVN05AC92Q0X PANEL TPT315B5-HVN05 S520D
MAIN BOARD
LOCATION PART NO. DESCRIPTION
WHOLE-ASSEMBLY 756TXECB01K007000X MAIN BOARD-CBPFE3SKX3
CAPACITOR
C603 067G315M1016HV EC 100UF 20% 35V 8*7
C602 067G315M1016HV EC 100UF 20% 35V 8*7
C749 065G040210131J F CAP 0402 100PF 5% 50V NP0
C650 065G040210131J F CAP 0402 100PF 5% 50V NP0
C632 065G040210131J F CAP 0402 100PF 5% 50V NP0
C649 065G040210131J F CAP 0402 100PF 5% 50V NP0
C710 065G040210131J F CAP 0402 100PF 5% 50V NP0
C646 065G040210131J F CAP 0402 100PF 5% 50V NP0
C643 065G040210131J F CAP 0402 100PF 5% 50V NP0
C701 065G040210131J F CAP 0402 100PF 5% 50V NP0
C156 065G040210131J F CAP 0402 100PF 5% 50V NP0
C702 065G040210232K F CAP 0402 1NF 10% 50V X7R
C432 065G040210232K F CAP 0402 1NF 10% 50V X7R
C431 065G040210232K F CAP 0402 1NF 10% 50V X7R
C133 065G040210232K F CAP 0402 1NF 10% 50V X7R
C104 065G040210232K F CAP 0402 1NF 10% 50V X7R
C628 065G040210232K F CAP 0402 1NF 10% 50V X7R
C160 065G040210232K T CAP 0402 1NF 10% 50V X7R UMK105 B7102KV
C161 065G040210232K T CAP 0402 1NF 10% 50V X7R UMK105 B7102KV
C159 065G040210232K T CAP 0402 1NF 10% 50V X7R UMK105 B7102KV
C166 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%
C171 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C170 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C163 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C167 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C135 065G040210412K A CAP CHIP 0402 100NF K 16V X7R
C403 065G040210412K F CAP 0402 100NF 10% 16V X7R
C736 065G040210412K F CAP 0402 100NF 10% 16V X7R
C627 065G040210412K F CAP 0402 100NF 10% 16V X7R
C748 065G040210412K F CAP 0402 100NF 10% 16V X7R
C404 065G040210412K F CAP 0402 100NF 10% 16V X7R
C402 065G040210412K F CAP 0402 100NF 10% 16V X7R
C719 065G040210412K F CAP 0402 100NF 10% 16V X7R
C415 065G040210412K F CAP 0402 100NF 10% 16V X7R
C413 065G040210412K F CAP 0402 100NF 10% 16V X7R
C429 065G040210412K F CAP 0402 100NF 10% 16V X7R
C417 065G040210412K F CAP 0402 100NF 10% 16V X7R
C418 065G040210412K F CAP 0402 100NF 10% 16V X7R
C433 065G040210412K F CAP 0402 100NF 10% 16V X7R
C622 065G040210412K F CAP 0402 100NF 10% 16V X7R
C409 065G040210412K F CAP 0402 100NF 10% 16V X7R
C623 065G040210412K F CAP 0402 100NF 10% 16V X7R
C122 065G040210412K F CAP 0402 100NF 10% 16V X7R
C715 065G040210412K F CAP 0402 100NF 10% 16V X7R
C411 065G040210412K F CAP 0402 100NF 10% 16V X7R
