Sharp LC-43CFE6131K Service Manual

52
LC-43CFE6452E
www.sharp.eu
DISPLAY
Diagonal screen size cm / inch 109/43
Panel resolution 1920x1080
Active motion 400
Backlight D-LED
Brightness (cd/m²) 300
Dynamic contrast 1 000 000:1
AUDIO SYSTEM
Speaker 2
Audio Power 2x8W (8 ohm)
Sound System B/G, D/K, I, L
NICAM/A2
Sound Settings Sound Equalizer
Audio decoder Dolby Digital/Digital+/DTS 2.0
Audio enhancement solution DTS TruSurround™
TUNER
TV system ATV PAL, SECAM
DTV DVB-T/T2/C/S/S2+MPEG4
FUNCTION
SHARP AQUOS NET+ Apps store YES
Pre-install Apps YouTube, Facebook, Twitter,
Web browser and many more
Hbb TV YES
DLNA media player
for Video / Photo / Music YES / YES / YES
Miracast YES
WiDi YES
WiFi YES
USB Video AVI/MKV/WMV/ASF/MP4/M4v/RM/
RMVB/VOB/TS/M2TS/MPG/FLV/SWF
USB Music MP3, M4a, WMA, AAC, AC3, EAC3,
LPCM, OGG
USB Photo JPG, JPEG, BMP, PNG
PVR Ready with timeshift YES (FAT32 only)
USB Software Update YES
USB le system FAT16/FAT32/NTFS
HDMI-CEC YES
HDMI-ARC YES (HDMI2)
MHL YES (HDMI3)
OAD YES
Digital Program List YES
Hotel Mode YES
CONNECTORS
HDMI-in YES (3x)
USB YES (2x)
RJ 45 (LAN) YES
SCART YES
WLAN YES
Common interface / CI+ YES
Antenna In (RF) YES
Sat In YES
Mini Component/YPbPr YES
Mini AV Composite input + Audio In YES
PC Input (D-sub15 pin) YES
PC Audio Input YES
Audio out / Headphone Jack YES
Digital Optical Audio Output YES
OTHERS
Power Requirements 220-240V ±20% / 50Hz
Safety Logo Certication CE (EMC), CB (Safety),
ErP (Energy) etc
ErP Compliant A+ Class
Power Consumption
(ecomode/standard/max) 41/50/70W
Power Consumption (Standby Mode) <0.50 W
VESA standard (mm) 400 x 200
EAN 4974019874968
Net size with stand (W x H x D in mm): 965,9 x 596,4 x 184,5
Net size without stand (W x H x D in mm): 965,9 x 571,2 x 67,1
Net weight with stand (kg) 7,8
Net weight without stand (kg) 7,6
The LC-40CFE6452E is an Full HD Smart D-LED TV
with exceptional picture quality.
CFE6450 series uses Direct LED lighting with an advanced structure of the optical distance between
the LED lights and the panel, as narrow as only 18mm which contributes to the very modern and slim
design of the TV set.
Product Fiche
Supplier trademark Sharp LC-40CFE6452E
Energy class A+
Screen size 100 cm / 40 inches
Power consumption 45.0 W
Annual energy consumption* 66 kWh
Standby power consumption <0.50 W
O mode power consumption Not applicable
Screen resolution 1920 (H) × 1080 (V)
* - Energy consumption XYZ kWh per year, based on the power consumption
of the television operating 4 hours per day for 365 days. The actual energy
consumption will depend on how television is used.
Sharp believe that seeing is believing /This is Why our
latest LED TVs feature innovative technologies for the most
vibrant, colourful picture yet.
LC-40CFE6452E
SCREEN SIZE 100 cm (40”)
HD TUNER DVB-T/T2/C/S/S2
3 HDMI INPUTS
USB FOR MULTIMEDIA
PLAYBACK AND RECORDING
SMART TV
400
ACE PRO

Sharp LC-43CFE6131K Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	43 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Motion interpolation technology	AMR (Active Motion Rate) 200
3D	No
News apps	BBC
Voltage tolerance	20 %
Annual energy consumption	60 kWh
Power consumption (average)	41 W
On/off switch	-
Product color	Black
Panel mounting interface	400 x 200 mm
Tuner type	Analog & digital
Analog signal format system	SECAM, PAL
Digital signal format system	DVB-T, DVB-T2, DVB-C
Video apps	YouTube
Sports apps	BBC Sports
Lifestyle apps	Facebook, Twitter
Audio decoders	Dolby Digital, DTS, DTS 2.0, Dolby Digital Plus
RMS rated power	16 W
Number of speakers	2
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Consumer Electronics Control (CEC)	Aquos Net+
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	70 W
Power consumption (standby)	0.5 W
Power consumption (typical)	50 W

Weight and Dimensions

Depth (with stand)	184.4 mm
Height (with stand)	596.4 mm
Weight (with stand)	8000 g
Depth (without stand)	67.1 mm
Width (without stand)	965.9 mm
Height (without stand)	558.3 mm
Weight (without stand)	7800 g
