LC-46SB57U/LC-52SB57U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE833FM05 CB N X MAIN Unit (DUNTKE833FM05S)
N DUNTKE264FM02 AP X R/C, LED Unit
N DUNTKE266FM02 AH X KEY Unit
N RDENCA336WJQZ BR X POWER Unit
N CPWBX4023TPXA BW N J LCD Control Unit (LC-46SB57U)
N CPWBX4023TPXZ BW N J LCD Control Unit (LC-52SB57U)
N RUNTKA538WJN1 BF N J INVERTER Unit-1 (LC-46SB57U)
N RUNTKA528WJN1 BF N J INVERTER Unit-1 (LC-52SB57U)
N RUNTKA539WJN1 BF N J INVERTER Unit-2 (LC-46SB57U)
N RUNTKA529WJN1 BF N J INVERTER Unit-2 (LC-52SB57U)
N RUNTKA540WJZZ AP N J INVERTER GND Unit-1 (LC-46SB57U)
N RUNTKA530WJZZ AP N J INVERTER GND Unit-1 (LC-52SB57U)
N RUNTKA541WJZZ AP N J INVERTER GND Unit-2 (LC-46SB57U)
N RUNTKA531WJZZ AP N J INVERTER GND Unit-2 (LC-52SB57U)
[2] LCD PANEL
N R1LK460D3LW80Z EL X 46" LCD Panel Module Unit (LK460D3LW80Z2)
N R1LK520D3LW80Z EY X 52" LCD Panel Module Unit (LK520D3LW80Z2)
[3] DUNTKE833FM05 (MAIN Unit)
C501 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C503 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C504 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C505 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C506 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C507 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C508 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C509 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C510 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C512 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C514 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C515 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C516 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C517 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C519 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C520 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C521 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C522 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C523 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C525 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C533 VCCCCZ1HH471JY AA J Capacitor 470p 50V Ceramic
C535 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C536 VCCCCZ1HH471JY AA J Capacitor 470p 50V Ceramic
C537 VCCCCZ1HH471JY AA J Capacitor 470p 50V Ceramic
C539 VCCCCZ1HH471JY AA J Capacitor 470p 50V Ceramic
C540 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C555 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C557 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C563 VCKYCY1EB103KY AA J Capacitor 0.01 25V Ceramic
C565 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C566 RC-KZA403WJPZY AB J Capacitor 4.7 6.3V Ceramic
C569 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C570 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C575 VCCCCZ1HH150JY AB J
Capacitor 15p 50V Ceramic
C576 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C577 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C578 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C579 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C580 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1101 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1102 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1107 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1112 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1116 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1119 VCKYCZ1AB473KY AB J Capacitor 0.047 10V Ceramic
C1124 VCKYCZ1EB472KY AB J Capacitor 4700p 25V Ceramic
C1125 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C1126 VCKYCY1EB104KY AB J Capacitor 0.1 25V Ceramic
C1129 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1130 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C1131 VCAAPE1AJ686MY AE J Capacitor 68 10V Electrolytic
C1134 VCAAPE1AJ686MY AE J Capacitor 68 10V Electrolytic
C1301 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1303 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1306 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1307 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1309 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1310 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1311 RC-KZA616WJQZY AB J Capacitor 10 10V Ceramic
C1312 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1314 RC-KZA098WJZZY AD J Capacitor 10 25V Ceramic
C1602 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C1603 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C1604 VCKYCZ1AB473KY AB J Capacitor 0.047 10V Ceramic
C1605 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
