Sharp LC-50LE752V - Removing of Major Parts - 50 Models (Continued); 50 Model Disassembly for Stand Bracket and Diffuser

31
LC-39/50LE750
LC-39/50LE751
LC-39/50LE752
2. Removing of major Parts 50” (Continued)
2.9. Remove the 6 lock screws ⑪ and detach the stand BRACKET.
2.10. Remove the 2 lock screws ⑫ and detach the control button HOLDER.
2.11. Detach the KEY unit ⑬ and the pyramid lighting DIFFUSER ⑭.
stand
BRACKET
piramid
lighting
DIFFUSER
KEY
unit
control
button
HOLDER
12
13
14
11
