Sharp LC-52LE832U - Heat Measure Sheet Location

LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
4 – 21
[5] The location putting on the heat measure sheet
1. MAIN PWB Unit
The object to cool.
(The sheet is put on the back of the
board.)
The guide line is impressed on the backlight
chassis
PSPAZC702WJKZ
Main PWB Unit
(DUNTKF733WE**)
