LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[5] CABINET PARTS (LC-52LE835U/830U/832U)
1 CCABAC655WJ31 BM N X Front Cabinet Ass'y (LC-52LE835U)
1 CCABAC655WJ32 BG N X Front Cabinet Ass'y (LC-52LE830U)
1 CCABAC655WJ33 BG N X Front Cabinet Ass'y (LC-52LE832U)
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - R/C Operation Cover
1-3 HDECQB541WJ3A AY N X Front Decoration(LC-52LE835U)
1-3 HDECQB605WJ3A AY N X Front Decoration(LC-52LE830U)
1-3 HDECQB605WJ3B AY N X Front Decoration(LC-52LE832U)
1-4 LHLDWA133WJKZ AC J Wire Holder
1-5 Not Available - N - Sheet
1-6 TLABZC680WJZZ AB N X Quattron 3D Label (LC-52LE835U)
1-6 TLABZC585WJZZ AF J Quattron Label (LC-52LE830U/832U)
1-7 TLABZC778WJZZ AA N X WiFi Label
2 CCABBB887WJ31 BF N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HiNDPE031WJSA AE N X Terminal Label (Width)
2-3 HiNDPE034WJSA AD N X Terminal Label (Back)
2-4 HiNDPE116WJSA AF N X Terminal Label (Length)
3 HDECPA090WJZZ AC N X Decoration Sheet (Side)
4 HDECPA091WJZZ AB N X Decoration Sheet (Bottom)
5 LANGKD121WJM1 AL N X Center Angle, x2
6 LANGKD146WJFW AD N X Terminal Angle Bottom
8 LHLDWA138WJKZ AC J Wire Holder, x2
9 LHLDWA175WJUZ AC J Wire Holder, x8
10 LHLDWA176WJUZ AC J Wire Holder
11 LX-BZA207WJF7 AA J Screw, x20
12 PSLDMB748WJFW AH N X Main PWB Shield
13 PSPAZC690WJZZ AC N X Spacer
14 PSPAZC691WJZZ AB N X Spacer, x3
15 PSPAZC702WJKZ AH N X Spacer
16 PZETKA580WJKZ AN N X Insulator Sheet
17 QCNW-L590WJQZ AN N X Connecting Cord (PD:MAIN-POW)
18 QCNW-L596WJQZ AE N X Connecting Cord (PL:MAIN-LCDCTL)
19 QCNW-L618WJQZ AF N X
Connecting Cord (SB:MAIN-WOOFER)
20 QCNW-L628WJQZ AR N X Connecting Cord (LW:MAIN-LCDCTL) (LC-52LE835U)
20 QCNW-L719WJQZ N X Connecting Cord (LV:MAIN-LCDCTL) (LC-52LE830U/832U)
21 QCNWN2733TPZZ AE N X Connecting Cord (80P:MDL-CTL), x2
22 QCNWN2734TPZZ AE N X Connecting Cord (64P:MDL-CTL), x2
23 RCORFA061WJZZ AG J Core, x4
24 XBPS830P06WS0 AA J Screw, x12
25 GCOVAC576WJKZ AC J Vesa Hole Cover, x4
26 GCOVAD969WJ3A AC N X AC Cord Cover
27 GCOVAD973WJ3A AD N X Bottom Cover
28 HiNDPE024WJSA AB N X Model Label (LC-52LE835U)
28 HiNDPE057WJSA AB N X Model Label (LC-52LE830U)
28 HiNDPE068WJSA AB N X Model Label (LC-52LE832U)
29 LANGKD124WJM1 AS N X Fixing Metal Angle
30 LANGKD127WJFW AA N X Fixing Metal Angle, x12
31 LHLDWA303WJKA AE J Cable Clamp
32 PSPAZC062WJKZ AG J Spacer
!
33 QACCDA084WJPZ AH N X AC Cord
34 QCNW-L597WJQZ AH N X Connecting Cord (UB:MAIN-WIFI)
35 QCNW-L600WJQZ AE N X Connecting Cord (RA:KEY-R/C)
36 QCNW-L601WJQZ AE N X Connecting Cord (CI:MAN-EMBLEM)
37 QCNW-L604WJQZ AG N X Connecting Cord (SP:MAIN-SP(L/R))
38 QCNW-L607WJQZ AR N X Connecting Cord (RC:MAIN-KEY/IR) (LC-52LE835U)
38 QCNW-L723WJQZ AP N X Connecting Cord (RC:MAIN-KEY) (LC-52LE830U/832U)
39 RSP-ZA512WJQZ AV N X Speaker (L/R), x2
40 RSP-ZA513WJQZ AV N X Speaker (Sub Woofer)
41 XBPS830P06WS0 AA J Screw, x24
42 XEBS830P08000 AA J Screw
43 XEBS830P12000 AA J Screw, x7
44 TLABNB037WJZZ AB N X Serial Label (Back)
45 Not Available - N - Serial Label (Side)
46 LHLDWA175WJUZ AC J Wire Holder
47 PZETKA605WJKZ AG N X Insulation Sheet
48 LX-BZA401WJN1 AB N X Screw, x3
