LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DKEYMF953FM06 BU N X MAIN Unit
N DUNTKF975FM20 N X LCD CONTROL Unit (LC-60/70LE650U/LE657U/C6500U)
N DUNTKF961FM19 N X LCD CONTROL UNIT (LC-60LE755U/757U/857U/C7500U)
N DUNTKF961FM20 N X LCD CONTROL UNIT (LC-70LE755U/757U/857U/C7500U)
[2] DKEYMF953FM06 (MAIN Unit)
C501 VCKYCZ1HB221KY AA J 220p 50V Ceramic
C502 VCKYCZ1HB221KY AA J 220p 50V Ceramic
C504 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C505 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C506 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C507 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C508 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C509 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C510 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C512 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C520 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C521 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C524 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C525 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C526 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C527 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C528 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C544 VCKYCZ1HB471KY AB J 470p 50V Ceramic
C545 VCKYCZ1HB471KY AB J 470p 50V Ceramic
C548 VCCCCZ1HH100DY AB J 10p 50V Ceramic
C549 VCCCCZ1HH100DY AB J 10p 50V Ceramic
C550 VCCCCZ1HH100DY AB J 10p 50V Ceramic
C554 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C555 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C558 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C559 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C560 VCKYCZ1HB102KY AB J 1000p 50V Ceramic
C577 RC-KZA761WJQZY AB J Capacitor
C578 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C579 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C580 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C584 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C586 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1106 VCCCCZ1HH100DY AB J
10p 50V Ceramic
C1108 V
CCCCZ1HH100DY AB J 10p 50V Ceramic
C1109 VCKYCZ1AB473KY AB J 0.047 10V Ceramic
C1110 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C1123 VCKYCZ1AB473KY AB J 0.047 10V Ceramic
C1124 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1127 RC-KZA510WJPZY AB J Capacitor
C1129 RC-KZA510WJPZY AB J Capacitor
C1185 VCKYCZ1EB103KY AA J 0.010 25V Ceramic
C1195 RC-KZA761WJQZY AB J Capacitor
C1196 RC-KZA761WJQZY AB J Capacitor
C1506 VCKYCZ1AB473KY AB J 0.047 10V Ceramic
C1507 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1508 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1509 RC-KZA510WJPZY AB J Capacitor
C1510 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1516 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1517 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1702 VCCCCZ1HH120GY AA J 12p 50V Ceramic
C1703 VCCCCZ1HH120GY AA J 12p 50V Ceramic
C1705 VCKYCZ1HB221KY AA J 220p 50V Ceramic
C1706 VCKYCZ1HB221KY AA J 220p 50V Ceramic
C1709 RC-KZA520WJQZY AA J Capacitor
C1710 RC-KZA520WJQZY AA J Capacitor
C1711 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1714 RC-KZA520WJQZY AA J Capacitor
C1715 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1716 VCCCCZ1HH391JY AA J 390p 50V Ceramic
C1717 VCCCCZ1HH391JY AA J 390p 50V Ceramic
C1718 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1719 RC-KZA520WJQZY AA J Capacitor
C1720 VCCCCZ1HH470JY AB J 47p 50V Ceramic
C1721 VCCCCZ1HH470JY AB J 47p 50V Ceramic
C1722 RC-KZA510WJPZY AB J Capacitor
C1723 VCKYCZ1AB104KY AB J 0.
10 10V Ceramic
C1724 RC-KZA510WJPZY AB J Capacitor
C1725 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1726 RC-KZA520WJQZY AA J Capacitor
C1727 RC-KZA520WJQZY AA J Capacitor
C1730 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1731 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1732 RC-KZA709WJQZY AA J Capacitor
C1903 RC-KZA838WJQZY AB J Capacitor
C1904 RC-KZA838WJQZY AB J Capacitor
C1905 VCKYCZ1AB104KY AB J 0.10 10V Ceramic
C1906 RC-KZA838WJQZY AB J Capacitor
