LC-60G9T / LC-70G9T
10 – 1
CHAPTER 10. SCHEMATIC DIA-
GRAM
[1] DESCRIPTION OF SCHEMATIC DIA-
GRAM
1. VOLTAGEMEASUREMENT CONDITION:
1) The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 110-240V.Signals are fedbyacolour bar signal
generator for servicing pur
pose and the above voltages are measured with a 20k ohm/V tester.
2. INDICATION OF RESISTOR & CAPACITOR:
RESISTOR
1)The unit of resistance ""is omitted.
(K=k =1000 , M=M ).
2) All resistors are ± 5%, unless otherwise noted.
(K= ± 10%, F= ± 1%, D= ± 0.5%)
3) All resistors are 1/16W, unless otherwise noted.
CAPACITOR
1) All capacitors are F, unless otherwise noted.
(P=pF=
F)
.
2) All capacitors are 50V, unless otherwise noted.
CAUTION:
T
his circuit diagram is original one,
therefore there may be
aslight
difference from yours.
SAFETY NOTES:
1) DISCONNECT THE AC PLUG FROM THE AC OUTLET
BEFORE REPLACING PARTS.
2) SEMICONDUC
TOR HEAT
SINKS SHOU
LD BE REGARDED AS
POTENTIAL SHOCK HAZARDS WHEN THE CHASSIS IS
OPERATING.
IMPORTANT SAFETY NOTICE:
P
ARTS MARKED WITH " "
( )
ARE IMPORTANT
FOR MAINTAINING
THE SAFETY OF THE SET.BESURETO
REPLACE THESE PARTS WITH SPECIFIED ONES FOR MAIN-
TAINING THE SAFETYAND PERFORMANCE OFTHE SET.
