LC-60G9T / LC-70G9T
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[5] CABINET AND MECHNICAL PARTS ( LC-70G9T )
1 CCABBC256WJ02 Rear Cabinet Ass'y
1-1 Not Available - - Rear Cabinet
1-2 Not Available - - Terminal Label (Back)
1-3 Not Available - - Terminal Label (Bottom)
1-4 LHLDWA318WJKZ AD Cable Tie
1-5 Not Available Himeron
1-6 Not Available Himeron
1-7 Not Available Himeron
1-8 Not Available Himeron
1-9 Not Available Himeron
1-10 Not Available - - Terminal Label (Side)
1-11 LHLDZB944WJKZ - - TENT-BOSHI-CRNP
1-12 XEBS840P14000 TENT-BOSHI-SCRW
2 CCOVAE693WJ21 FRONT COVER ASS'Y
2-1 NOT AVAILABLE 3D IR COVER
2-2 NOT AVAILABLE - - Front Cover
2-3 NOT AVAILABLE - - Led Cover
2-4 HDECSA106WJ2A Shine Trim
3 GCOVAE537WJ2A BTM Cover
4 CCOVAE513WJ04 KEY Button Cover Ass'y
4-1 Not Available - - KEY Button Cover
4-2 Not Available - - Key Label
4-3 JBTN-A984WJKA Key Button
5 GCOVAE530WJ2A Decoration Cover (Rear)
6 GCOVAE555WJ2A AC Cord Cover
7 TLABZD807WJZZ Energy Guide Label
8 MODEL LABEL
8 HINDPE945WJZZ A1KUTG9DTL
10 QACCDA084WJPZ AH AC Cord
11 QCNW-M3 7 3WJQZ AG Connecting Cord (SP)
12 QCNW-M544WJZZ AD Connecting Cord (UB)
13 QCNW-N2 4 7WJZZ AH Connecting Cord (RC)
14 QCNW-N3 0 2WJZZ AL Connecting Cord (BT) (LC-70LE755U/757U/857U)
15 RSP-ZA572WJZZ AT Speaker (L/R)
16 RSP-ZA575WJZZ BB Speaker (Woofer)
18 TLABNF022WJZZ SIDE SERIAL LBL
19 XBPS830P06WS0 SCREW,X53
20 XEBS830P12000 SCREW,X12
21 CANGKD762WJ01 BL SUPPORT ANGLE ASS'Y (BOTTOM)
22 CHLDZB969WJ01 P CHASSIS UNIT (TOP-L)
23 CHLDZB970WJ01 P CHASSIS UNIT (TOP-R)
24 CHLDZB971WJ01 P CHASSIS UNIT (BOTTOM M-L)
25 CHLDZB972WJ01 P CHASSIS UNIT (BOTTOM R)
26 CHLDZB973WJ01 P CHASSIS UNIT (L)
27 CHLCZB974WJ01 P CHASSIS UNIT (R)
28 CANGKD506WJ01 VESA ANGLE ASS'Y,X4
29 CANGKD761WJ01 SUPPORT ANGLE ASS'Y (TOP)
30 CCHSMA676WJ02 BL CHASSIS UNIT ASS'Y
31 CHLDZB982WJ01 S-PWB HOLDER ASS'Y,X4
32 HDECPA091WJ4A DECORATION SHEET (BOTTOM)
34 CANGKE052WJ02 TERMINAL ANGLE (SIDE)
35 CANGKE053WJ01 TERMINAL ANGLE (BOTTOM)
36 LANGKD759WJ3W AF Stand Angle, x2
37 LHLDWA289WJKZ AC Wire Holder
38 LX-BZA207WJF7 AA Screw, x20
39 LX-LZ0003TPZZ AC Rivet, x20
42 PSPAZD031WJKZ AE Cooler, x2
43 QCNW-M534WJZZ AC Connecting Cord (SB)
44 QCNW-N0 7 5WJQZ AM Connecting Cord (L1)
45 QCNW-N0 7 6WJQZ AN Connecting Cord (L2)
46 QCNW-N190WJQZ AF Connecting Cord (FFC 80p), x2
47 QCNW-N19 1WJQZ AF Connecting Cord (FFC 64p), x2
48 QCNW-N2 4 1WJZZ AU Connecting Cord (LV)
49 QCNW-N2 5 4WJZZ AQ Connecting Cord (PD)
50 RCORFA061WJZZ AG Ferrite Core, x4
52 CWAKMA035WJ03 BF Aluminum Frame Ass'y (Top)
53 CWAKMA036WJ03 BK Aluminum Frame Ass'y (Bottom)
54 CWAKMA037WJ03 BE Aluminum Frame Ass'y (Left)
55 CWAKMA038WJ03 BE Aluminum Frame Ass'y (Right)
56 LANGKD774WJFW AE Corner Angle, x4
57 LX-BZA505WJF8 AA Screw, x16
58 TLABZD612WJZZ AA License Label
59 TLABZD636WJSA AB 3D Quattron Label
60 PGiDMA066WJZZ BT LGP
61 PMiR-A3 29WJ3A AZ Reflector
62 PSHEPB250WJ3A BB Diffuser
63 PSHEPB251WJN1 BE Lens Sheet
64 PSHEPB252WJZZ BC Lens Sheet
65 QCNW-N118WJQZ AH FFC30P:S-G(L)
66 QCNW-N119WJQZ AH FFC30P:S-G(R)
67 TLABN2229TPZZ AA Module Label
68 TLABN3860TPZZ AA BL Label
70 XBPS830P08000 SCREW.X30
71 XBSS730P06000 SCREW,X2
72 RUNTKB077WJZZ AZ B/L LED Unit, x6
