Sharp LC-80LE632U - CHAPTER 2. OPERATION MANUAL; OPERATION MANUAL

LC-80LE632U
2 – 1
LC80LE632U
Service Manual
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
Part Names
TV (Front/Side)
Center Icon
illumination
Remote
control sensor
*1 Button operations.
*2 OPC: Optical Picture Control
OPC sensor *2
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH /)
Volume
buttons
(VOL /)
*1
TV (Rear )
RS-232C terminal
Antenna/
Cable in
AC INPUT terminal
COMPONENT
terminals
DIGITAL AUDIO
OUTPUT terminal
HDMI 3 terminal
HDMI 4 terminal
HDMI 1 terminal
ARC:Audio Return Channel
VIDEO 2
terminals
VIDEO 1
terminals
AUDIO OUT terminal
USB 1 terminal
USB 2
terminal
ETHERNET
terminal
HDMI 2 terminal
PC IN terminal
*2
*2
*1
*2
AUDIO IN terminal
(shared for PC IN
and HDMI 1) *3
*1 Connecting the AC cord.
*2 External equipment connection.
*3 Details on the Audio Select function.
