NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
MD-R2
! F551,552 92LFUSET102H J AD Fuse,1A
FL901 VVK15BT37G/-1 J BD FL Display
J101 92LJACKL1779A J AG Jack,Analog Line Out
J301 QJAKZ0011AWZZ J AE Jack,Digital In
J981 QJAKJ0006AWZZ J AG Jack,Headphones
M901 RMOTV0012AWZZ J AV MD Spindle Motor Ass’y
M902 RMOTV0013AWM1 J AQ MD Sled Motor Ass’y
M903 RMOTV0014AWM1 J AQ MD Loading Motor Ass’y
RX302 VHPGP1F32R/-1 J AP Optical Fiber Data Link,
GP1F32R
SW501 92LSWICH-1385A J AC Switch,Key Type [Reset]
SW901 QSW-Z0003AWZZ J AH Switch,Push Type [Jog]
SW950 QSW-K0006AWZZ J AC Switch,Key Type [Power]
SW951 QSW-K0006AWZZ J AC Switch,Key Type [Play]
SW952 QSW-K0006AWZZ J AC Switch,Key Type [Stop]
SW953 QSW-K0006AWZZ J AC Switch,Key Type [Rec]
SW954 QSW-K0006AWZZ J AC Switch,Key Type [Cue]
SW955 QSW-K0006AWZZ J AC Switch,Key Type [Eject]
SW956 QSW-K0006AWZZ J AC Switch,Key Type [Enter]
SW957 QSW-K0006AWZZ J AC Switch,Key Type [Name]
SW958 QSW-K0006AWZZ J AC Switch,Key Type [Timer]
SW959 QSW-K0006AWZZ J AC Switch,Key Type [Disp]
SW960 QSW-K0006AWZZ J AC Switch,Key Type [Review]
SW961 QSW-K0006AWZZ J AC Switch,Key Type [Aux]
SW962 QSW-K0006AWZZ J AC Switch,Key Type [Program]
SW1952 QSW-P0006AWZZ J AG Switch,Push Type [Direct]
SW1953 QSW-M0157AFZZ J AD Switch,Push Type [Lead In]
SW1954 QSW-M0002AWZZ J AD Switch,Push Type [Play]
SW1955 QSW-M0002AWZZ J AD Switch,Push Type [Rec]
SW1956 QSW-M0001AWZZ J AD Switch,Push Type [Loading]
TX302 VHPGP1F32T/-1 J AP Optical Fiber Data Link,
GP1F32T
UN970 VHL21043TH2-1 J AG Remote Sensor,21043TH2
MECHANICAL PARTS
1 LANGF0033AWZZ J AD Bracket,MD Guide (A)
2 LANGF0034AWZZ J AD Bracket,MD Guide (B)
3 LANGK0092AWFW J AM Frame
4 LCHSM0060AWM1 J AP Chassis,Drive
5 LHLDX3001AWM1 J AP Holder,Cartridge Ass’y
6 MLEVF0024AWM1 J AF Lever,Cam Plate Ass’y
7 MLEVF0025AWZZ J AD Lever,H/A Shift
8 MLEVF0026AWZZ J AF Lever,Holder Arm
9 MLEVF0029AWM1 J AL Lever,Roller Arm Sub Ass’y
10 MLEVP0075AWZZ J AD Lever,Clamp
11 MLEVP0076AWZZ J AC Lever,Catch
12 MLEVP0077AWZZ J AC Lever,Slider
13 MSPRD0103AWFJ J AB Spring,Roller Holder
14 MSPRD0105AWFJ J AB Spring,Spindle
15 MSPRD1318AFFJ J AB Spring,Shift Arm
16 MSPRD1319AFFJ J AB Spring,Holder Arm
17 MSPRD1321AFFJ J AB Spring,Lack
18 MSPRD1334AFFJ J AC Spring,Catch
19 MSPRP0015AWFJ J AB Spring,Plate (A)
20 MSPRP0017AWFJ J AB Spring,Drive Shaft
21 MSPRT1566AFFJ J AB Spring,Roller Arm
22 NGERH0066AWZZ J AC Gear,Loading (B)
23 NGERH0067AWZZ J AC Gear,Drive
24 NGERH0068AWZZ J AC Gear,Loading (A)
25 NGERH0069AWZZ J AC Gear,Roller
26 NGERR0002AWZZ J AC Gear,Rack
29 NROLP0010AWZZ J AC Holder,Roller
30 NROLR0001AWZZ J AC Transfer Roller
31 NSFTD0005AWFT J AF Shaft,Drive
32 NSFTM0017AWFW J AC Shaft,Loading Gear
33 NSFTM0277AFFW J AC Shaft,Pickup Slide
34 NSFTM0278AFFW J AC Shaft,Pickup Guide
35 PCOVS3021AWFW J AL Cover,Shield Top
37 PCUSG0531AFSA J AD Cushion (A)
38 PCUSG0531AFSB J AD Cushion (B)
39 PCUSS0041AWZZ J AC Cushion,Head
40 RCILH0108AFZZ J AP Magnetic Head
! 41 RCTRH8173AF10 J Pickup Unit
42 QCNWN6715AFM1 J AM MD Flat Cable,24Pin
45 PSHEP0024AWZZ J AC Sheet,Head
46 MLEVP0078AWZZ J AC Arm (A)
47 MLEVP0079AWZZ J AC Arm (B)
48 LANGF0036AWZZ J AC Bracket,Cartridge
49 MSPRT0020AWFJ J AB Spring,Arm
50 PSHEP0026AWZZ J AC Sheet,Head Lead Wire
51 LANGZ0020AWFW J AM Bracket,Protect
601 LX-BZ0030AWZZ J AB Screw,ø1.7×9.5mm
602 LX-BZ0031AWZZ J AB Screw,ø1.7×7.5mm
603 LX-BZ0032AWZZ J AB Screw,ø1.7×2mm
604 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
605 LX-BZ0846AFZZ J AB Screw,ø1.7×3mm
606 LX-BZ0851AFZZ J AB Screw,ø1.7×2.5mm
607 LX-BZ0852AFFD J AC Screw,ø1.7×8.9mm
608 LX-BZ0883AFZZ J AB Screw,ø1.7×5mm
609 LX-WZ9268AFZZ J AA Washer,ø1.5×ø3.2×0.5mm
610 LX-WZ9269AFZZ J AA Washer,ø1.2×ø3×0.25mm
611 XBPSD20P04K00 J AA Screw,ø2×4mm with Washer
612 XSPSN17P03K00 J AB Screw,ø1.7×3mm
613 LX-BZ0034AWZZ J AC Screw,Special Type
M901 RMOTV0012AWZZ J AV MD Spindle Motor Ass’y
M902 RMOTV0013AWM1 J AQ MD Sled Motor Ass’y
M903 RMOTV0014AWM1 J AQ MD Loading Motor Ass’y
SW1952 QSW-P0006AWZZ J AG Switch,Push Type [Direct]
SW1953 QSW-M0157AFZZ J AD Switch,Push Type [Lead In]
SW1954 QSW-M0002AWZZ J AD Switch,Push Type [Play]
SW1955 QSW-M0002AWZZ J AD Switch,Push Type [Rec]
SW1956 QSW-M0001AWZZ J AD Switch,Push Type [Loading]
CABINET PARTS
201 92LCAB2627AS1 J AY Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 92LBADGE1692A J AC Badge,SHARP
203 HDECQ0273AWSA J AK FL Window
204 JKNBK0050AWSA J AC Knob,Jog Volume
205 JKNBK0051AWSA J AC Knob,Rec Volume
206 HDECQ0274AWSA J AK Decoration,Jog
207 HDECQ0275AWSA J AK Decoration,MD
208 GDORF0048AWSA J AF MD Door
209 MSPRT0021AWZZ J AB Spring,MD Door
210 JKNBZ0462AWSA J AE Knob,Power
211 JKNBZ0439AWSA J AF Knob,Operation
212 JKNBZ0441AWSA J AE Knob,Eject
213 PRDAR0041AWFW J AG Heat Sink
214 LHLDZ1168AWZZ1 J AE FL Holder
215 GITAR0288AWSA J AR Back Panel
! 216 QACCD0014AWZZ J AK AC Power Supply Cord
! 217 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
218 92LN-BAND1318A J AA Nylon Band,80mm
219 LCHSM0062AWFW J AW Main Chassis
220 LANGZ0018AWFW J AG Bracket,MD Support
221 GLEGP0006AWSA J AE Insulator
222 GLEGP0006AWSB J AG Insulator
224 PCUSG0029AW00 J Cushion,PWB
225 92LCAB2627CS1 J BB Top Cabinet
! 226 92LFSHOLD1652T J AB Holder,Fuse
! 227 92LLUG1746A J AA Lug,Terminal
228 QCNWN1174AWZZ J AC Tip with Wire
229 92LCAUT1472A J AA Caution,Fuse
601 LX-EZ0005AWFD J AA Screw,Special
602 XEBSD26P10000 J AA Screw,ø2.6×10mm
603 XJBSD30P08000 J AA Screw,ø3×8mm
604 XEBSF26P10000 J AA Screw,ø2.6×10mm
605 LX-JZ0010AFFD J AA Screw,ø3×10mm
606 XJBSF30P10000 J AA Screw,ø3×10mm
607 XHBSD40P08000 J AA Screw,ø4×8mm
608 XWSSD40-11000 J AA Washer,ø4mm
609 XJBSD30P06000 J AA Screw,ø3×6mm
610 XJSSD30P08000 J AA Screw,ø3×8mm
611 XWHFZ32-05070 J AA Washer,ø3.2×ø7×0.5mm
612 LX-WZ0014AGFK J AA Washer,ø2.6mm
ACCESSORIES
QCNWG0003AWZZ J AN Pin Cord
TINSE0191AWZZ J AG Operation Manual
TINSZ0283AWZZ J AB Quick Guide
TLABM0051AWZZ J AC Feature Label
RRMCG0123AWSA J AY Remote Control
92LLID1810A J AQ Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A 92LPWB2628MANS J — Main
PWB-B1~3 92LPWB2628DPLS J — Display/Switch/Headphones
(Combined Ass'y)
– 4 –
