Sharp MX-3140N Technical Guide

SHARP
TEST SIMULATION
51
66
Fax Control Settings & Adjustments
1
Fax Soft SW setting:-
SW27-6
V.34 mode function (manual
communication):-
0 = V.34 valid.
1 = V.34 invalid.
SW33-6,7
Transmission cable amplitude
equaliser:-
00 = 0dB
01 = 4dB
10 = 8dB
11 = 12dB
2
Country code default set (Fax)
3
Fax PWB controller memory check
4
Fax signal line check (Max level)
5
Fax signal line check (Soft SW setting level)
6
Fax list print (confidential registration)
7
Fax memory printout (all data)
8
Fax sound message setup
9
Fax signal line check (Soft SW setting)
10
Fax all memory clear
11
Voice signal check (line/speaker 300bps)
12
Voice signal check (line/speaker 300bps)
13
Register dial number for Sim 66-14/15/16
14
Adjust/check the time dial pulse (10bps)
15
Adjust/check the time dial pulse (20bps)
16
Adjust/check the send level DTFM signal
17
DTFM signal to send to line (Max level)
18
DTFM signal to send to line (Soft Sw level)
21
Print various registration information
22
Set the sound volume of the handset
24
Fast memory data clear
29
Fax address book clear
30
Tel/LIU sensor status check
31
ON/OFF setting of output port (Tel/LIU)
32
Received data check (comparison)
33
Busy Tone/CNG/CED/FNET detect check
34
Display time required for sending test data
36
Check Send/Receive from modem.
39
Check Destination saved in Fax EEPROM
42
Rewrite PIC program installed on Fax box
43
Write program & adjustment values to PIC
installed on Fax
61
Display FAX related soft switch (151-250)
62
FAX receive data export in PDF format.
67
Printer Settings & Adjustments
17
Printer NVRAM clear
24
Printer half tone auto adjustment
25
Printer half tone colour adjustment
26
Standard target select of printer half tone
auto adjustment
27
Scanner target of printer calibration setup
(Service)
28
Standard target of printer colour
calibration (Service)
31
Printer calibration data clear
33
Printer screen gamma adjust. (PCL/PS)
34
Engine maximum adjustment mode for
printer
36
Adjust low density section
41
Threshold value setting for printing
judgement of the black colour in B/W
printing or selected colour.
42
Gradation setting amount for the black
colour in B/W printing or selected colour.
43
Colour balance adjustment of fine B/W
printing.
45
Printer image filter and trapping
adjustment.
52
Printer default gamma check (PCL/PS)
54
Printer colour balance adjustment

Sharp MX-3140N Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	31 ppm
Print Resolution	1200 x 1200 dpi
Copy Speed	31 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Paper Capacity	600 sheets
Duplex Printing	Yes
Network Connectivity	Ethernet
Connectivity	USB, Ethernet
Display	7-inch color touchscreen
Operating System Compatibility	Windows, Mac
