Sharp MX-3140N Technical Guide

TROUBLE CODES
SHARP
52
A0
01
PCU ROM abnormality
02
SCU ROM abnormality
04
ACU/ACRE expansion ROM error
10
Colour profile error
11
Firmware discrepancy (MFP-PCU)
14
MFP-CPU firmware inconsistency
15
Incompatible DSK Boot and program
firmware version
16
Data error of Energy Saving NIC firmware
on SD card.
17
UI data & CPU firmware inconsistency.
20
Firmware & EEPROM conflict (MFP)
21
Firmware & EEPROM conflict (PCU)
22
Firmware & EEPROM conflict (SCU)
C1
10
Main charger trouble (Monochrome)
14
Main charger trouble (Colour)
C4
00
PTC trouble (TC high voltage)
CE
00
Network communication error
01
Network card is not installed or defective
02
FTP or Mail server is not found
03
Specified server does not correspond
during transmission
04
Invalid account/password (FTP server)
05
Invalid directory entered (FTP server)
06
Specified mail server (POP3) is not found
07
Invalid server account or password
08
The specified mail server (POP3) suspends
response
E7
01
MFP image data trouble.
02
HDD trouble when the mirroring kit is
installed.
03
HDD trouble.
04
HDD-ASIC error.
07
SD Card error
10
Shading trouble (Black correction).
11
Shading trouble (White correction).
14
CCD-ASIC communication error.
20
LSU laser detection error (K).
E7
20
LSU laser detection error (K).
21
LSU laser detection error (C).
22
LSU laser detection error (M).
23
LSU laser detection error (Y).
24
LSU LD driver error (K)
25
LSU LD driver error (C)
26
LSU LD driver error (M)
27
LSU LD driver error (Y)
28
LSU-PCU connection trouble
29
LSU-ASIC frequency abnormality.
42
Image data trouble (ACRE - ASIC)
46
Image data decode error ( ACRE)
47
MFP & ACRE firmware inconsistency
48
Scanner expansion PWB (ACRE) memory
error
49
Watermark data error
50
Firmware & PWB combination error
55
PCU PWB information sum error
60
MFP combination error (Firmware/PWB)
61
MFP-PCU combination error
65
MFP EEPROM sum check error
80
MFP-SCU communication trouble.
89
Communication error between MFP PWB
& Energy Saving NIC controllers.
90
MFP-PCU communication trouble.
91
Fax reception image data error
92
Copy image data error
93
Image data process error.
94
Image data process error (import data)
95
Printer PWB DIMM memory check error.
96
MFP PWB DIMM memory check error.
A0
LSU LD PWB EEPROM R/W error (K)
A1
LSU LD PWB EEPROM R/W error (C)
A2
LSU LD PWB EEPROM R/W error (M)
A3
LSU LD PWB EEPROM R/W error (Y)
A5
Mirror kit HDD installation error
A6
Compact Flash memory trouble
EE
EC
Auto DV adjustment trouble.
EL
Auto DV adjustment trouble (over toned).
EU
Auto DV adjustment trouble (under toned).
F1
00
Finisher-PCU PWB communication error.
03
Finisher exit roller lifting operation trouble

Sharp MX-3140N Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	31 ppm
Print Resolution	1200 x 1200 dpi
Copy Speed	31 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Paper Capacity	600 sheets
Duplex Printing	Yes
Network Connectivity	Ethernet
Connectivity	USB, Ethernet
Display	7-inch color touchscreen
Operating System Compatibility	Windows, Mac
