MX3500N SIMULATION 7 – 80
ORG RECOG
(Document type
auto recognition)
STATISTICS
(Image process
statistic amount)
HTHSTDG Mesh pixel histogram value (GREEN) Max. 10 digits #1 to #32 display A3
pixel number
HTHSTDB Mesh pixel histogram value (BLUE) Max. 10 digits
LHSTD L component histogram value other
than mesh
Max. 10 digits
MDHSTD Max. difference histogram value other
than mesh
Max. 10 digits
OHSTDR Pixel histogram value other than mesh
(RED)
Max. 10 digits
OHSTDG Pixel histogram value other than mesh
(GREEN)
Max. 10 digits
OHSTDB Pixel histogram value other than mesh
(BLUE)
Max. 10 digits
SUM_BETA_RGB Total of high-level division number in
background pixel histogram
0 to 32
EREA_BETA RGB Number of high-level division areas in
background pixel histogram (for base)
0 to 16
SUM_BETA_PHOTORGB Number of high-level division areas in
background pixel histogram (for
photographic paper)
0 to 16
RATE_BETA Background ratio 0 to 10000
SHITAJI Base number judgment result 0 to 3
BETA_JUDGE Background judgment result 0 to 8
RATE_SCR Mesh ratio 0 to 10000
RATE_SCR2 Mesh judgment ratio 0 to 10000
RATE_TSCR Text-on-mesh ratio 0 to 10000
HTFE_JUDGE Line number judgment result Max. 3 digits
SCR_HIST_JUDGE Mesh histogram judgment result 0 to 2
SCR_CNT_JUDGE Mesh counter value judgment result 0 to 1
TSCR_JUDGE Text-on-mesh counter value judgment
result
0 to 2
SCR_JUDGE Mesh judgment result 0 to 5
RATE_OTHER Other ratio 0 to 10000
TEXT_JUDGE Text judgment result 0 to 1
PHOTO_CNT_JUDGE Photographic paper pixel counter value
judgment result
0 to 1
OTHER_JUDGE Other pixel counter value judgment
result
0 to 1
PHOTO_JUDGE Photographic paper judgment result 0 to 1
TH_BETA2 Threshold value to detect high-level
division in background pixel histogram
A3 pixel
number
TH_BETA_PHT2 Threshold value to detect high-level
division in background pixel histogram
(photographic paper)
Max. 2 digits
TH_SCR2 Mesh high-level threshold value Max. 5 digits A3 pixel number
TH_SCR_CNT2 Threshold value for the mesh counter
value
Max. 5 digits
TH_TSCR_CNT2 Threshold value for the text-on-mesh
counter value
Max. 5 digits A3 pixel number
TH_TEXT2 Text judgment threshold value Max. 10 digits A3 pixel number
TH_PHOTO2 Photographic paper judgment threshold
value
Max. 10 digits A3 pixel number
ALLCNT Total pixel number of judgment area Max. 10 digits A3 pixel number
HTFE RESULT HIGH2 Number of
mesh lines
High number of lines 2
(htfe_out = 3)
2
HIGH1 High number of lines 1
(htfe_out = 2)
1
LOW1 Low number of lines 1
(htfe_out = 1)
3
LOW2 Low number or lines 2
(htfe_out = 0)
4
REVERSE AVE Max. reverse average 0 to 100.00 ********: ave_m (When
100 is exceeded, "-" is
displayed.)
REVERSE AVE(FLAT) Flat section max. reverse average 0 to 100.00 ******** : ave_fm
(When 100 is
exceeded, "-" is
displayed.)
FLAT SELECT YES Flat section
mesh pixel
comparison
When flatr > THflatr 0
NO When other than flatr >
THflatr
1
Category Detail of category Display Content
Set range/
Number of
digits
Remark
