MX3500N MAINTENANCE 9 – 4
2. Details of maintenance
A. Drum peripheral
: Check (Clean, replace, or adjust according to necessity.) {: Clean : Replace : Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical
parts
When
calling
150
K
300
K
450
K
600
K
750
K
900
K
1050
K
1200
K
1350
K
1500
K
1650
K
1800
K
Remark/Refer to
the Parts Guide.
Block/Item No.
(Only the
replacement parts
are described.)
Color supply
100
K
200
K
300
K
400
K
500
K
600
K
1 Drum (BK) Monochrome
supply
2 Cleaner blade (BK) (P/G No.: [23]-14)
3 Charging unit (BK) (P/G No.: [23]-2)
4 Drum (C) Color supply
5 Cleaner blade (C) (P/G No.: [23]-14)
6 Charging unit (C) (P/G No.: [23]-2)
7 Side seal F/R (BK) Mechanical
parts
8 Toner reception
seal (BK)
9 Side seal F/R(C)
10 Toner reception
seal (C)
11 Waste toner box
3,6
7,9
8,10
2,5
7,9
1,4
11
To Next Page
