MX3500N SIMULATION 7 – 82
<Set range and default value of each setup>
Category Item Display Content Set range/Number of digits
Default
value
Screen
type
ACS 4 digits or
less setting
A THCLMK_1 Pixel judgment threshold value
(1)
0 – 9 7
A
B THCLBK_1 Final pixel judgment threshold
value (1)
0 – 3 2
C ACSMSK_1 ACS mask size select (1) 0 – 1 0
D THCLMK_2 Pixel judgment threshold value
(2)
0 – 9 7
E THCLBK_2 Final pixel judgment threshold
value (2)
0 – 3 2
F ACSMSK_2 ACS mask size select (2) 0 – 1 0
G THCLMK_3 Pixel judgment threshold value
(3)
0 – 9 7
H THCLBK_3 Final pixel judgment threshold
value (3)
0 – 3 2
I ACSMSK_3 ACS mask size select (3) 0 – 1 0
J THCLMK_4 Pixel judgment threshold value
(4)
0 – 9 7
K THCLBK_4 Final pixel judgment threshold
value (4)
0 – 3 2
L ACSMSK_4 ACS mask size select (4) 0 – 1 0
M THCLMK_5 Pixel judgment threshold value
(5)
0 – 9 7
N THCLBK_5 Final pixel judgment threshold
value (5)
0 – 3 2
O ACSMSK_5 ACS mask size select (5) 0 – 1 0
P SIM_LEVEL ACS judgment select switch
(density difference)
1 – 3 2
Q TH_ACS5_RT TH_ACS5: Calculation ratio of
the threshold value for
reduction
0 – 100 50
5 digits or
less setting
A TH_ACS5 ENLARGE ACS judgment threshold value
5 (for enlargement)
0 – 134217727
(A3 pixel number)
000030000 B
COLOR AE 4 digits or
less setting
A SW_MODE1 ON Base detection of auto text
document
0 –
1
11A
OFF 0
B SW_MODE2 ON Base detection of auto text
mesh document
0 –
1
11
OFF 0
C SW_MODE3 ON Base detection of auto text-on-
mesh document
0 –
1
11
OFF 0
D SW_MODE4 ON Base detection of auto mesh
document
0 –
1
10
OFF 0
E SW_MODE5 ON Base detection of auto photo
document
0 –
1
10
OFF 0
F SW_MODE6 ON Base detection of auto text/
photo document
0 –
1
10
OFF 0
G SW_MODE7 ON Base detection of auto other
document
0 –
1
10
OFF 0
H TH_MAX_MONO Monochrome base detection
threshold value
0 – 32
17
I TH_MAX_COLOR Color base detection threshold
value
0 – 32
17
J SW_NEWS Newspaper base forcible
removal switch
0 – 1
0
K SW_MODE_SCR1 Mesh area base judgment
switch
1 – 3
3
L SW_MODE_SCR2 Mesh area base removal select
switch
0 – 1
0
M SW_MODE_MIX Auto other document base
detection switch
1 – 2
2
N SW_HOSEI Correction table correction 0 – 8 (-4 – +4) 4
5 digits or
less setting
A TH_MODE_SCR Mesh ratio threshold value 0 – 10000 03000 B
B TH_SITAJI_SCR Base mesh threshold value 0 – 10000 03000
