MX3500N SIMULATION 7 – 85
SCR RECOG 4 digits or
less setting
F THBAVEM3 ENLARGE Threshold value 3 for 13 x 7
mask average value (for
enlargement)
0 – 255 50 A
G CMSUB1 REDUCE Adjustment value 1 for 13 x 7
mask average value (for
reduction)
0 – 255 55
H CMSUB1 ENLARGE Adjustment value 1 for 13 x 7
mask average value (for
enlargement)
0 – 255 55
I CMSUB2 REDUCE Adjustment value 2 for 13 x 7
mask average value (for
reduction)
0 – 255 0
J CMSUB2 ENLARGE Adjustment value 2 for 13 x 7
mask average value (for
enlargement)
0 – 255 0
K MREVSEL REDUCE High line number judgment
method select (for reduction)
0 – 3 0
L MREVSEL ENLARGE High line number judgment
method select (for
enlargement)
0 – 3 0
M MSDSEL REDUCE Output select when
MREVSEL=3 (for reduction)
0 – 1 0
N MSDSEL ENLARGE Output select when
MREVSEL=3 (for enlargement)
0 – 1 0
O THAVEFM1 REDUCE THAVEFM1 for reduction 0 – 720 65
P THAVEFM1 ENLARGE THAVEFM1 for enlargement 0 – 720 96
Q THAVEFM2 REDUCE THAVEFM2 for reduction 0 – 720 54
R THAVEFM2 ENLARGE THAVEFM2 for enlargement 0 – 720 80
S THAVEFM3 REDUCE THAVEFM3 for reduction 0 – 720 48
T THAVEFM3 ENLARGE THAVEFM3 for enlargement 0 – 720 70
U THAVEM1 REDUCE THAVEM1 for reduction 0 – 720 65
V THAVEM1 ENLARGE THAVEM1 for enlargement 0 – 720 96
W THAVEM2 REDUCE THAVEM2 for reduction 0 – 720 54
X THAVEM2 ENLARGE THAVEM2 for enlargement 0 – 720 80
Y THAVEM3 REDUCE THAVEM3 for reduction 0 – 720 48
Z THAVEM3 ENLARGE THAVEM3 for enlargement 0 – 720 70
SEGMENT 4 digits
or less
setting
Tex t-o n-
mesh ON/
OFF (auto/
manual
mode)
A MESH_TXT ON HT (Auto) text on mesh 0 –
3
0
(THROUGH)
0
(THROUGH)
A
B MESH_TXT/HT1 (Auto) text mesh (Under 1, Line
1)
1 (OFF)
C MESH_TXT/HT2 (Auto) text mesh (Under 2, Line
1)
2 (ON1)
D MESH_TXT/PR (Manual) test print 3 (ON2)
Print
document
text
detection
level
E PR_TXT ON HT (Auto) Text on mesh 0 –
3
0
(THROUGH)
F PR_TXT/HT1 (Auto) text mesh (Under 1, Line
1, 2)
1(ON1)
G PR_TXT/HT2 (Auto) text mesh (Under 1, Line
1, 2)
2 (ON2)
H PR_TXT/PR (Manual) Text print 3 (ON3)
I PR_CHECK1(*2) ON Check button for investigation
[(Auto) text on mesh]
0 –
1
00
OFF 1
J PR_CHECK2(*2) ON Check button for investigation
[(Auto) Text mesh (Under 2,
Line 1, 2)]
0 –
1
00
OFF 1
K PR_CHECK3(*2) ON Check button for investigation
[(Auto) Text mesh (Under 2,
Line 1, 2)]
0 –
1
00
OFF 1
L PR_CHECK4(*2) ON Check button for investigation
[(Manual) text print]
0 –
1
00
OFF 1
M THWMAX(*2) THWMAX (Print document text
detection level)
0 – 255 220
N THWMIN(*2) THWMIN (Print document text
detection level)
0 – 255 153
Category Item
Display Content Set range/Number of digits
Default
value
Screen
type
