MX3500N SIMULATION 7 – 107
(Initial screen or when in normal end)
(Adjustment screen)
(Error end screen)
Main scan
adjustment
error
50 MAIN BLACK FRONT Number error main scan BLACK F The number of pitch data is not the specified number.
51 MAIN BLACK FRONT Pitch error main scan BLACK F The pitch data is not in the specified allowable range.
55 MAIN BLACK REAR Number error main scan BLACK R The number of pitch data is not in the specified range.
56 MAIN BLACK REAR Pitch error main scan BLACK R The pitch data is not in the specified allowable range.
60 MAIN CYAN FRONT Number error main scan CYAN F The number of pitch data is not the specified number.
61 MAIN CYAN FRONT Pitch error main scan CYAN F The pitch data is not in the specified allowable range.
62 MAIN CYAN FRONT Adjustment value error main scan
CYAN F
The calculation result value is not in the specified allowable
range.
63 MAIN CYAN FRONT Result value error main scan CYAN
F
The variation of the calculation result value is over the
specified allowable range.
65 MAIN CYAN REAR Number error main scan CYAN R The number of pitch data is not the specified number.
66 MAIN CYAN REAR Pitch error main scan CYAN R The pitch data is not in the specified allowable range.
67 MAIN CYAN REAR Adjustment value error main scan
CYAN R
The calculation result value is not in the specified allowable
range.
68 MAIN CYAN REAR Result value error main scan CYAN
R
The variation of the calculation result value is over the
specified allowable range.
70 MAIN MAGENTA FRONT Number error main scan MAGENTA
F
The number of pitch data is not the specified number.
71 MAIN MAGENTA FRONT Pitch error main scan MAGENTA F The pitch data is not in the specified allowable range.
72 MAIN MAGENTA FRONT Adjustment value error main scan
MAGENTA F
The calculation result value is not in the specified allowable
range.
Main scan
adjustment
error
73 MAIN MAGENTA FRONT Result value error main scan
MAGENTA F
The variation of the calculation result value is over the
specified allowable range.
75 MAIN MAGENTA REAR Number error main scan MAGENTA
R
The number of pitch data is not the specified number.
76 MAIN MAGENTA REAR Pitch error main scan MAGENTA R The pitch data is not in the specified allowable range.
77 MAIN MAGENTA REAR Adjustment value error main scan
MAGENTA R
The calculation result value is not in the specified allowable
range.
78 MAIN MAGENTA REAR Result value error main scan
MAGENTA R
The variation of the calculation result value is over the
specified allowable range.
80 MAIN YELLOW FRONT Number error main scan YELLOW
F
The number of pitch data is not the specified number.
81 MAIN YELLOW FRONT Pitch error main scan YELLOW F The pitch data is not in the specified allowable range.
82 MAIN YELLOW FRONT Adjustment value error main scan
YELLOW F
The calculation result value is not in the specified allowable
range.
83 MAIN YELLOW FRONT Result value error main scan
YELLOW F
The variation of the calculation result value is over the
specified allowable range.
85 MAIN YELLOW REAR Number error main scan YELLOW
R
The number of pitch data is not the specified number.
86 MAIN YELLOW REAR Pitch error main scan YELLOW R The pitch data is not in the specified allowable range.
87 MAIN YELLOW REAR Adjustment value error main scan
YELLOW R
The calculation result value is not in the specified allowable
range.
88 MAIN YELLOW REAR Result value error main scan
YELLOW R
The variation of the calculation result value is over the
specified allowable range.
Other error 99 OTHER Other error Other error
Error
code
Error display Error content Detail of content
0
SIM ULATI ON  NO.50-22
TEST
AUTO ADJUSTMENT OF REGISTRATION&DLUM POSITION
EXECUTE
MAIN F M A IN R S U B PH ASE
C 105.0 (+0.2) 110.0 (-0.1) 103.0 (+0.4) 4 (3)
M 100.0 (+0.0) 99.0 (-0.2) 99.0 (+0.2)
Y 98.0 (+0.3) 98.0 (+0.1) 105.0 (+0.0)
1/1
CLOSE
REGIST DRUM POS ALL
0
SIMULATION NO.50-22
TEST
AUTO ADJUSTMENT OF REGISTRATION&DLUM POSITION
CLOSE
EXECUTE
NOW EXECUTING…
0
SIMULATION NO.50-22
TEST
AUTO ADJUSTMENT OF REGISTRATION&DLUM POSITION
CLOSE
EXECUTE
PRESS [EXECUTE] TO START
ERROR : TONNER EMPTY 01
