1-152
BEFORE USING THE MACHINE►MAINTENANCE
4
Make sure that the cleaner at the tip of
the cleaning tool is not dirty.
If the cleaner is dirty, remove the cleaner from the cleaning
tool and replace it with a clean one. For the procedure for
replacing the cleaner, see steps 5 through 7. If the cleaner
is not dirty, go to step 8.
5
Take out a replacement cleaner from
the waste toner box.
Replacement cleaners are stored on the waste toner box.
Grasp the end of the cleaner and pull it out of the waste
toner box.
6
Remove the dirty cleaner from the tip
of the cleaning tool.
(1) Firmly grasp the tool where the cleaner is
attached.
(2) Use your other hand to press down on the
hook that secures the cleaner, and
remove the cleaner.
Put the removed cleaner back on the waste toner box.
7
Attach the new cleaner to the cleaning
tool.
(1) Align the cleaner hook with the
attachment hole in the cleaning tool.
(2) Hold the cleaner firmly and push the
cleaning tool in.
To Next Page
