Sharp MX-5111N - Page 46

TEST SIMULATION
SHARP
46
60
Memory Operation & Test
1
SDRAM read/write test (ICU)
61
LSU Writing Adjustment/Test
1
LSU test (Polygon & BD detection check)
3
LSU power auto setup
4
LSU position adjustment (CMYK)
62
HDD Operation & Test
1
HDD format (FAT32)
2
HDD partial read/write check
3
HDD read/write check (all areas)
6
Smart (HDD) self diagnostic test
7
Smart (HDD) self diagnostic error log
8
HDD format (excluding system &
operation manual area)
10
Job completion list deletion (with job log)
11
Document filing data deletion
12
Enable/disable auto format for HDD
trouble.
13
HDD format (manual area only)
14
Delete document filing management data
16
Job Log Optimisation
20
Check operation of mirroring hard disk
63
CCD Operation & Adjustment
1
Shading correction data display
2
Shading correction execution (force)
3
CCD gamma & colour correction adjust.
4
SIT chart patch density list display
5
CCD gamma & colour correction reset.
6
Print engine colour balance
7
Standard target colour calibration set-up
8
Standard scanner target reset (Service)
11
Colour Balance setting (Factory Mode).
64
Self Test Print
1
Self print test (Colour mode)
2
Engine colour balance patch print mode
3
Self print test (B/W mode)
4
Printer self print test
5
Printer self print test (PCL)
6
Printer self pint test (PS)
7
Adjustment pattern print (Sim46-21)
65
LCD Operation & Adjustment
1
LCD touch panel adjustment
65
LCD Operation & Adjustment
2
LCD touch panel adjustment result display
5
Operation panel key input test
66
Fax Control Settings & Adjustments
1
Fax Soft SW setting
2
Country code default set (Fax)
3
Fax PWB controller memory check
4
Fax signal line check (Max level)
6
Fax list print (confidential registration)
7
Fax memory printout (all data)
8
Fax voice message setup
9
Fax signal line check (Soft SW setting)
10
Fax all memory clear
11
Voice signal check (line/speaker 300bps)
12
Voice signal check (line/speaker 300bps)
13
Register dial number for Sim 66-14/15/16
14
Adjust/check the time dial pulse (10bps)
15
Adjust/check the time dial pulse (20bps)
16
Adjust/check the send level DTFM signal
17
DTFM signal to send to line (Max level)
18
DTFM signal to send to line (Soft Sw level)
19
Write Fax Pwb SRAM data to Flashcard
20
Write telephone book data onto HDD
21
Print various registration information
22
Set the sound volume of the handset
24
Fast memory data clear
29
Fax address book clear
30
Tel/LIU sensor status check
31
ON/OFF setting of output port (Tel/LIU)
32
Received data check (comparison)
33
Busy Tone/CNG/CED/FNET detect check
34
Display time required for sending test data
36
Check Send/Receive from modem.
39
Check Destination saved in Fax EEPROM
42
Rewrite PIC program installed on Fax box
43
Write program & adjustment values to PIC
installed on Fax
61
Display FAX related soft switch (151-250)
62
FAX receive data export in PDF format.
67
Printer Settings & Adjustments
17
Printer NVRAM clear
24
Printer half tone auto adjustment
25
Printer half tone colour adjustment
26
Standard target select of printer half tone
auto adjustment
