Ver. 2.0U Dec. 4, 2008
- 5 - Installation Manual for PV modules
e
e
e
e
g
g
g g
s s
s s
Figure 12 (NT/NE series)
Figure 9 (ND series)
uu uu
Figure 12 (NT/NE series)
Figure 9 (ND series)
Figure 10 (NT/NE series)
8.3” (210 mm) ＜ g ＜18.5” (470 mm)
Figure 11 (ND series)
9.3” (235 mm) ＜ e ＜19.4” (495 mm)
Figure 13 (ND series)
9.3” (235 mm) ＜ s ＜ 19.4” (495 mm)
8.3” (210 mm) ＜ u ＜ 18.5” (470 mm)
Figure 14 (NT/NE series)
