Sharp ND-U230C1 - Electrical Information; Electrical Ratings

Ver. 2.0U Dec. 4, 2008
- 6 - Installation Manual for PV modules
C) ELECTRICAL INFORMATION
ELECTRICAL RATINGS
Rated electrical characteristics are within ±10 percent of the indicated values of Isc, Voc and within +10/-5 percent of Pmax under Standard Test
Conditions (irradiance of 100 mW/cm
2
, AM 1.5 spectrum, and a cell temperature of 25˚C (77˚F)). The warranty conditions are specified elsewhere in
this manual.
ND-U230C1 ND-U224C1 ND-U216C1
Maximum Power (Pmax)
230.0 W 224.0 W 216.0 W
Open-Circuit Voltage (Voc)
37.0 V 36.9 V 36.7 V
Short-Circuit Current (Isc)
8.24 A 8.07 A 7.85 A
Voltage at maximum power (Vpmax)
30.3 V 30.2 V 30.2 V
Current at maximum power (Ipmax)
7.60 A 7.42 A 7.16 A
Maximum System Voltage
600 V 600 V 600 V
Minimum Blocking diode
15 A 15 A 15 A
Series Fuse
15 A 15 A 15 A
ND-224UC1 ND-220UC1 ND-216UC1 ND-208UC1 ND-200UC1
Maximum Power (Pmax)
224.0 W 220.0 W 216.0 W 208.0 W 200.0 W
Open-Circuit Voltage (Voc)
36.6 V 36.5 V 36.5 V 36.3 V 36.01 V
Short-Circuit Current (Isc)
8.33 A 8.24 A 8.10 A 7.99 A 7.90 A
Voltage at maximum power (Vpmax)
29.28 V 29.19 V 28.9 V 28.71 V 28.42 V
Current at maximum power (Ipmax)
7.66 A 7.54 A 7.48 A 7.25 A 7.04 A
Maximum System Voltage
600 V 600 V 600 V 600 V 600 V
Minimum Blocking diode
15 A 15 A 15 A 15 A 15 A
Series Fuse
15 A 15 A 15 A 15 A 15 A
NT-175UC1 NT-170UC1 NE-170UC1 NE-165UC1
Maximum Power (Pmax)
175.0 W 142.0 W 170.0 W 165.0 W
Open-Circuit Voltage (Voc)
44.4 V 43.2 V 43.2 V 43.1 V
Short-Circuit Current (Isc)
5.40 A 5.47 A 5.47 A 5.31 A
Voltage at maximum power (Vpmax)
35.4 V 34.8 V 34.8 V 34.6 V
Current at maximum power (Ipmax)
4.95 A 4.90 A 4.90 A 4.77 A
Maximum System Voltage
600 V 600 V 600 V 600 V
Minimum Blocking diode
10 A 10 A 10 A 10 A
Series Fuse
10 A 10 A 10 A 10 A
Under normal conditions, a PV module may produce more current and/or voltage than reported at Standard Test Conditions. Accordingly, the values
of Isc and Voc marked on UL 1703 listed modules should be multiplied by a factor of 1.25 when determining component voltage ratings, conductor
ampacities, fuse sizes and size of controls connected to the module output. Refer to Sec. 690-8 of the National Electric Code for an additional
multiplying factor of 125 percent (80 percent de-rating) which may be applicable. Where Canadian UL listing applies, installation shall be in
accordance with CSA C22.1, Safety Standard for Electrical Installations, Canadian Electrical Code, Part 1.
