REMOTE CONTROL
1 TRANSMITTER
2 DISPLAY
3 ON/OFF Button
4 THERMOSTAT Button
5 DISPLAY Button
6 1-HOUR OFF TIMER Button
7 PLASMACLUSTER Button
8 TIMER ON Button
9 MODE Button
10 TIMER OFF Button
11 FAN Button
12 TIMER CANCEL Button
13 SWING Button
14 RESET Button
15 FULLPOWER Button
16 SELF CLEAN Button
17 COANDA AIRFLOW Button
DISPLAY
1
2
3
4
5
6
7
8
9
1 MODE Symbols
: AUTO : HEAT
: COOL : DRY
2 FULL POWER Symbol
3 SELF CLEAN Symbol
4 PLASMACLUSTER Symbol
5 FAN SPEED Symbols
: AUTO
: Manual setting
6 COANDA AIRFLOW Symbol
7 TEMPERATURE AND TIMER
COUNT DOWN Indicator
8 TRANSMITTING Symbol
9 TIMER ON / TIMER OFF Indicator
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
