Sharp PN-CD701 Supplemental Information

Port
number
Protocol
Remarks
8883
MQTT
443
MQTT over
WebSockets
5671
AMQP
443
AMQP over
WebSockets
443
HTTPS
4-3. Technical background
Tips: Required network connection for IoT sensors is always LAN 2
Required port(s) for uploading / downloading IoT sensor data
Internet connections
Condition of IP address
4-3-2. Network requirements for SWS (IoT sensor data)
It can use DHCP. And supports both IPv4 and IPv6.
Internet connections are available using intranet. If network devices filter IoT packets, they can accessed though router, proxy, GW/FW.
11
4-3-3. Other network requirements
Port “80” and “843” are required by Crestron connected.

Sharp PN-CD701 Specifications

General

Response time	6 ms
Display diagonal	70 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	4000:1
Display number of colors	1.06 billion colors
Display diagonal (metric)	176.6 cm
Viewing angle, horizontal	176 °
Number of simultaneous touchpoints	10
RMS rated power	24 W
Number of built-in speakers	2
Wi-Fi	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	5
Windows operating systems supported	Windows 10
AC input voltage	100-240 V
Heat dissipation	801 BTU/h
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	370 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE, CB
Sustainability certificates	RoHS
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	41 mm
Placement supported	Indoor
Bezel width (bottom)	53 mm
Panel mounting interface	400 x 400 mm
Purpose	Corporate
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	90 mm
Width	1623 mm
Height	976.4 mm
Weight	65000 g
