When a USB type-C cable is connected, the functions shown it the table below are available.
The USB Type C cable may also provide power to the connected PC.
Contact your local electrical contractor before running the supplied cable under carpets,
behind walls or over ceiling tiles, as regulations may vary.
If you use 8m USB type-C cable(PN-ZU01), please observe the following points. It may cause a fire.
Caution for running USB type-C cable
6
Do not use the USB type-C cable rolled/tied up.
Do not lay the USB type-C cable under the carpet.
Do not to be routed inside the building structure (e.g., walls, ceilings, etc.).
If a cable is damaged, never use the cable.
If you connect this cable to PN-CD701, please fix the cable with a clamp.
This cable has a “SOURCE” connector and a “DISPLAY” connector.
Be careful not to mistake the orientation.
Figure. Fixed the cable
Figure. Connector
Function of USB type-C Available/
Not Available
DP Alt mode(Video stream) Available
Network * Available
Touch (Data Transport) Available
Power Delivery Available(MAX 60W)
Table. Function of USB type-C
3. Outline of USB type-C
“In case you using USB-C cable from your market (not
delivered with PN-CD701), the take care the this cable
should be supported power charging of 60W or more.”
[Note]

Other manuals for Sharp PN-CD701

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sharp PN-CD701 and is the answer not in the manual?

Sharp PN-CD701 Specifications

General IconGeneral
Response time6 ms
Display diagonal70 \
Display brightness350 cd/m²
Display technologyLCD
Native aspect ratio16:9
Contrast ratio (typical)4000:1
Display number of colors1.06 billion colors
Display diagonal (metric)176.6 cm
Viewing angle, horizontal176 °
Number of simultaneous touchpoints10
RMS rated power24 W
Number of built-in speakers2
Wi-Fi-
USB version2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity5
Windows operating systems supportedWindows 10
AC input voltage100-240 V
Heat dissipation801 BTU/h
AC input frequency50 - 60 Hz
Power consumption (standby)- W
Power consumption (typical)370 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
CertificationCE, CB
Sustainability certificatesRoHS
OrientationHorizontal/Vertical
Product colorBlack
Product designDigital signage flat panel
Bezel width (side)41 mm
Placement supportedIndoor
Bezel width (bottom)53 mm
Panel mounting interface400 x 400 mm
PurposeCorporate
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth90 mm
Width1623 mm
Height976.4 mm
Weight65000 g
