Sharp PN-CD701 Supplemental Information

◆ USB type-C Out can be used for video output.
◆ About “Multi board”
Caution for running USB type-C cable
7
Figure. Rear Left View
• Only video signals are output from USB type-C Out.
• The signal of Wireless Cast can not be output.
• Do not convert the cable from the USB type-C cable.
• Only the same display or allowed display is supported for the display connected to the Out side.
3. Outline of USB type-C
You can display video on a second device using USB-C Out.
The USB-C cable enables touch without connecting a touch cable.
If you want to touch on the second display, please connect as follows.
*Touch settings on the PC must be set.
USB-C cable
Touch cable
(USB-B cable)
HDMI cable
PC
PC
OR
2
nd
unit
1
st
unit of PN-CD701
PC
Figure. Daisy chain connection

Sharp PN-CD701 Specifications

General

Response time	6 ms
Display diagonal	70 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	4000:1
Display number of colors	1.06 billion colors
Display diagonal (metric)	176.6 cm
Viewing angle, horizontal	176 °
Number of simultaneous touchpoints	10
RMS rated power	24 W
Number of built-in speakers	2
Wi-Fi	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	5
Windows operating systems supported	Windows 10
AC input voltage	100-240 V
Heat dissipation	801 BTU/h
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	370 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE, CB
Sustainability certificates	RoHS
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	41 mm
Placement supported	Indoor
Bezel width (bottom)	53 mm
Panel mounting interface	400 x 400 mm
Purpose	Corporate
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	90 mm
Width	1623 mm
Height	976.4 mm
Weight	65000 g
