34
R-1200
R-1201
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
*
*
*
∆
*
ELECTRIC PARTS
1- 1 FH-DZB016MRY0 M High voltage rectifier assembly 1 AH
1- 2 RC-QZB018MRE0 M High voltage capacitor 1 AG
1- 3 QFS-TA013WRE0 M Temperature fuse 150˚C (Magnetron) 1 AE
1- 4 RMOTDA211WRE0 M Turntable motor 1 AL
1- 5 QFS-TA014WRE0 M Temperature fuse 150˚C (Cavity) 1 AF
1- 6 RMOTEB031MRE0 M Fan motor 1 AR
1- 7 RTRN-B068MRE0 M Power transformer 1 BC
1- 8 RV-MZA288WRE0 M Magnetron 1 BK
1- 9 QFSHDB003MRE0 M Fuse holder 1 AD
1-10 QSW-MA085WRE0 M Primary interlock and door sensing switches 2 AE
1-11 FFS-BA016/KIT M Monitor switch (V-16G-2C25) with fuse (20A) assembly 1 AF
1-12 FACCDB011MRE0 M Power supply cord 1 AQ
1-13 QSOCLB006MRE0 M Oven lamp socket 3 AE
1-14 RLMPTA068WRE0 M Oven lamp 3 AE
CABINET PARTS
2- 1 HDECQB033MRF0 M Bottom sash [R-1200] 1 AH
2- 1 HDECQB034MRF0 M Bottom sash [R-1201] 1 AK
2- 2 GDAI-B066MRP0 M Base plate R 1 AF
2- 3 GCABUB108MRP0 M Outer case cabinet [R-1200] 1 AZ
2- 3 GCABUB109MRP0 M Outer case cabinet [R-1201] 1 AZ
2- 4 TMAPCB068MRR0 M Schematic diagram 1 AB
2- 5 FANGKB009MRY0 M Hood lamp glass assembly [R-1200] 1 AN
2- 5 FANGKB010MRY0 M Hood lamp glass assembly [R-1201] 1 AM
2-5-1 LANGQB016MRP0 M Hood lamp glass angle [R-1200] 1 AG
2-5-1 LANGQB020MRP0 M Hood lamp glass angle [R-1201] 1 AG
2-5-2 PGLSPB004MRE0 M Hood lamp glass 1 AH
2- 6 PCOVPB099MRT0 M Base cover [R-1200] 1 AR
2- 6 PCOVPB100MRT0 M Base cover [R-1201] 1 AS
RIGHT PANEL PARTS
3- 1 DPWBFB102MRU0 M Power unit 1 AZ
3- 1A QCNCMA017JDZZ M 3-pin connector CN-A 1 AG
3- 1B QCNCMA275DRE0 J 2-pin connector CN-B 1 AB
3- 1C QCNCMA470DRZZ J 9-pin connector CN-C 1 AF
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 VCEAB31HW477M J Capacitor 470 uF 50V 1 AE
C21 VCEAB31VW106M J Capacitor 10 uF 35V 1 AB
D1-4 RH-DZA006PRE0 J Diode (1N4002) 4 AD
D20-24 VHD1SS270A/-1 J Diode (1SS270A) 5 AA
D40 VHD1SS270A/-1 J Diode (1SS270A) 1 AA
Q21 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
Q22 VSKRA101M//-3 J Transistor (KRA101M) 1 AB
R1-2 VRS-B13AA241J J Resistor 240 ohm 1W 2 AB
R4 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
RY1-2 RRLY-A113DRE0 M Relay (DU24D1-1PR(M)) 2 AG
RY3-4 RRLY-B004MRE0 M Relay (FTR-F3AA024E) 2 AG
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB017MRE0 M Transformer 1 AS
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
3- 2 HPNLCB150MRF0 M Right panel [R-1200] 1 AR
3- 2 HPNLCB151MRF0 M Right panel [R-1201] 1 AR
3- 3 JBTN-B116MRF0 M Open button [R-1200] 1 AE
3- 3 JBTN-B117MRF0 M Open button [R-1201] 1 AE
3- 4 MSPRTA050WRE0 M Button spring 1 AA
3- 5 PSHEPB076MRR0 M Menu label 1 AG
3- 6 XEPSD30P10XS0 M Screw; 3mm x 10mm 2 AB
OVEN PARTS
4- 1 PDUC-B118MRF0 M Exhaust duct 1 AH
4- 2 FROLPB025MRK0 M Turntable support assembly 1 AN
4- 3 NTNT-A095WRE0 M Turntable tray 1 AN
4- 4 LBNDKB009MRP0 M Capacitor holder 1 AB
4- 5 PDUC-B111MRF0 M Magnetron duct 1 AF
4- 6 MLEVPB016MRF0 M Open lever 1 AD
4- 7 ************* M Oven cavity (Not replaceable part) 1 --
∆
