29
R-120DB
R-120DK
R-120DR
R-120DW
∆
∆
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
∆
*
ELECTRIC PARTS
1- 1 QSW-MA137WRE0 Secondary interlock switch & door sensing switch 2 AH
1- 2 FFS-BA027WRKZ
C/T fuse (120˚C, 13A) & monitor switch (AM51620C53Y1) assembly 1AS
1- 3 FACCDA079WRE0 Power supply cord 1 AF
1- 4 QSOCLA021WRE0 Oven lamp socket 1 AH
1- 5 FH-DZA095WRKZ High voltage rectifier 1 AQ
1- 6 RC-QZA209WRE0 High voltage capacitor 1 AX
1- 7 RMOTEA383WRE0 Fan motor 1 AV
1- 8 RV-MZA195WRE0 Magnetron 1 BK
1- 9 RLMPTA068WRE0 Oven lamp 1 AG
1-10 RMOTDA211WRE0 Turntable motor 1 AS
1-11 RTHM-A117WRE0 Thermal cut-out 95˚C 1 AQ
1-12 RTRN-A606WRZZ Power transformer 1 BM
CABINET PARTS
2- 1 GCABUA754WRPZ Outer case cabinet [R-120DB] 1 BC
2- 1 GCABUA763WRPZ Outer case cabinet [R-120DK] 1 BC
2- 1 GCABUA765WRPZ Outer case cabinet [R-120DR] 1 BC
2- 1 GCABUA761WRPZ Outer case cabinet [R-120DW] 1 BC
2- 2 GDAI-A325WRWZ Bottom plate 1 AF
2- 3 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 DPWBFC045WRUZ Control unit 1 BB
3- 2 FPNLCB485WRKZ Panel frame with key unit 1 AY
3- 2-1 HPNLCB607WRFZ Control panel 1 AN
3- 2-2 PSHEPA723WREZ Key sheet 1 AM
3- 3 PPACGA175WREZ Packing 1 AF
OVEN PARTS
4- 1 PHOK-A117WRPZ Latch hook 1 AH
4- 2 PDUC-A740WRWZ Air intake duct 1 AD
4- 3 LBNDKA132WRP0 H.V. Capacitor holder 1 AD
4- 4 PDUC-A736WRPZ Magnetron air duct 1 AF
4- 5 PDUC-A743WRPZ Exhaust duct 1 AD
4- 6 PCUSUA541WRPZ Cushion 1 AC
4- 7 PDUC-A745WRWZ Fan duct 1 AE
4- 8 NFANJA029WRE0 Fan blade 1 AL
4- 9 PCUSUA540WRPZ Cushion 1 AC
4-10 PDUC-A752WRFZ Top air separator 1 AD
4-11 ************* Oven cavity (Not replaceable part) 1--
4-12 PCOVPA359WREZ Waveguide cover 1 AD
4-13 GLEGPA078WRFZ Leg (Left) 1 AE
4-14 GLEGPA079WRFZ Leg (Right) 1 AE
4-15 PDUC-A746WRFZ Air separator 1 AE
4-16 PSKR-A367WRFZ Barrier 1 AE
4-17 PCUSGA541WRPZ Cushion 2 AC
4-18 PPACGA097WRE0 O-ring 1 AG
4-19 PCUSUA542WRPZ Cushion 1 AC
4-20 PCUSUA527WRP0 Cushion 1 AE
4-21 PCUSUA543WRPZ Cushion 1 AC
4-22 PCUSUA544WRPZ Cushion 1 AC
4-23 LANGTA369WRPZ Chassis support 1 AF
4-24 PDUC-A753WRPZ Air duct 1 AE
4-25 LANGTA370WRPZ Support angle 1 AD
DOOR PARTS
5- 1 FDORFA341WRTZ Door panel 1 AX
5- 2 GWAKPA705WRRZ Door frame [R-120DB] 1 AY
5- 2 GWAKPA719WRRZ Door frame [R-120DK] 1 AY
5- 2 GWAKPA721WRRZ Door frame [R-120DR] 1 AY
5- 2 GWAKPA717WRRZ Door frame [R-120DW] 1 AY
5- 3 JBTN-B119WRFZ START/MINUTE PLUS button and STOP/CLEAR button 2 AE
5- 4 MSPRTA196WREZ Button spring 2 AC
5- 5 LSTPPA194WRFZ Latch head 1 AE
5- 6 MSPRTA084WRE0 Latch spring 1 AB
5- 7 PSHEPA722WREZ Sealer film 1 AE
5- 8 GCOVHA418WRFZ Choke cover 1 AL
5- 9 LSTPPA196WRFZ Door stopper 1 AC
