39
R-1405
R-1406
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
3- 2-2 JBTN-B141MRF0 M Open button [R-1406] 1 AE
3- 2-3 HPNLCB172MRF0 M Control panel frame [R-1405] 1 AT
3- 2-3 HPNLCB173MRF0 M Control panel frame [R-1406] 1 AT
3- 2-4 MSPRTA050WRE0 M Button spring 1 AA
3- 3 XEPSD30P10XS0 M Screw; 3mm x 10mm 5 AB
OVEN PARTS
4- 1 LSTPPB038MRF0 M Door stopper 1 AB
4- 2 FROLPB025MRK0 M Turntable support assembly 1 AN
4- 3 NTNT-A108WRE0 M Turntable tray 1 AM
4- 4 LBNDKB009MRP0 M Capacitor holder 1 AB
4- 5 PDUC-B111MRF0 M Magnetron duct 1 AF
4- 6 MLEVPB016MRF0 M Open lever 1 AD
4- 7 ************* M Oven cavity (Not replaceable part) 1 --
4- 8 PPACGB014MRF0 M Turntable motor packing 1 AA
4- 9 PHOK-B018MRF0 M Latch hook 1 AF
4-10 FANGTB005MRY0 M Unit mounting plate assembly 1 AS
4-11 NFANPB006MRE0 M Fan blade 1 AC
4-12 LBSHC0037WRE0 M Cord bushing 1 AB
4-13 MLEVFB007MRP0 M Mounting lever 2 AC
4-14 PDUC-B112MRP0 M Hood intake duct R 1 AG
4-15 PCOVPB085MRP0 M Waveguide cover 1 AH
4-16 MSPRTA046WRE0 M Latch spring 2 AB
4-17 LANGTB055MRP0 M Chassis support 2 AD
4-18 PDUC-B115MRF0 M Hood duct R 1 AQ
4-19 PDUC-B114MRF0 M Hood duct L 1 AQ
4-20 PDUC-B113MRP0 M Fan duct 1 AH
4-21 PDUC-B117MRF0 M Orifice 1 AC
4-22 PCUSGB043MRP0 M Transformer cushion 1 AC
DOOR PARTS
5 CDORFB321MRK0 M Door assembly [R-1405] 1 BB
5 CDORFB322MRK0 M Door assembly [R-1406] 1 BB
5- 1 FDORFB070MRT0 M Door panel assembly 1 AW
5- 2 FCOV-B225MRK0 M Door frame assembly [R-1405] 1 AY
5- 2 FCOV-B226MRK0 M Door frame assembly [R-1406] 1 AY
5-2-1 LSTPPB023MRF0 M Latch head 1 AC
5-2-2 MSPRTA046WRE0 M Latch spring 1 AB
5- 3 GCOVHB044MRF0 M Choke cover 1 AG
5- 4 PSHEPB021MRE0 M Sealer film 1 AE
5- 5 HPNL-B102MRE0 M Door screen 1 AH
5- 6 XCPSD40P08000 M Screw : 4mm x 8mm 2 AA
MISCELLANEOUS
6- 1 CFZK-B460MRK0 M Installation material assembly 1 AH
6-1-1 LBSHC0040MRE0 M Grommet 1 AC
6-1-2 LX-BZ0195WRE0 M Toggle screw 4 AC
6-1-3 LX-MZB001MRE0 M Cord holder 1 AB
6-1-4 XBRSD50P60000 M Screw : 5mm x 60mm 2 AA
6-1-5 XOTSD40P12000 M Screw : 4mm x 12mm 3 AA
6-1-6 XTSSD50P35000 M Screw : 5mm x 35mm 6 AA
6-1-7 XWHSD50-16300 M Washer 2 AA
6-1-8 LANG-B002MRP0 M Scale plate 2 AD
6- 2 TINSEB318MRK0 M Operation manual 1 AD
6- 3 TINSKB081MRR0 M Top template 1 AB
6- 4 QW-QZB025MRE0 M High voltage wire A 1 AT
6- 5 FW-VZB202MRE0 M Main harness 1 AT
6- 6 TCAUAB041MRR0 M DHHS service caution label 2 AA
6- 7 TCAUAB045MRR0 M Monitor caution label 1 AA
6- 8 TCAUAB005MRR0 M Revised DHHS/GRD C/label 1 AB
6- 9 FW-VZB189MRE0 M Low voltage harness 1 AT
6-10 PFIL-B002MRE0 M Grease filter 2 AF
6-11 FFTA-B005MRK0 M Exhaust damper assembly 1 AH
