HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PACKING AND ACCESSORIES
4-3
TURNTABLE TRAY
TOP PAD
BOTTOM PAD
PACKING CASE
ACCESSORY PACK
WRAP COVER
DOOR PAD
SPADFA020WRE0
Non-replaceable items
DOOR PROTECTOR
GREASE FILTER (x 2)
6-10
INSTALL MATERIAL ASSEMBLY
6-1
6-2
OPERATION MANUAL
6-3
TOP/WALL TEMPLATE
EXHAUST DAMPER
ASSEMBLY
6-11
SCREWS,NUTS AND WASHERS
7- 1 LX-CZB004MRE0 M Special screw (R-1405) 3 AA
7- 1 LX-CZB016MRE0 M Special screw (R-1406) 3 AA
7- 2 XOTSE40P12000 M Screw : 4mm x 12mm (R-1405) 5 AA
7- 2 XOTSF40P12000 M Screw : 4mm x 12mm (R-1406) 5 AB
7- 3 XOTSD40P12000 M Screw : 4mm x 12mm 18 AA
7- 4 XHTSD40P08RV0 M Screw : 4mm x 8mm 4 AA
7- 5 LX-CZA038WRE0 M Special screw 9 AA
7- 6 LX-CZ0052WRE0 M Special screw 2 AA
7- 7 XCPSD30P08000 M Screw : 4mm x 8mm 2 AA
7- 8 LX-BZA041WRE0 M Special screw 5 AA
7- 9 XCBSD30P08000 M Screw : 3mm x 8mm 1 AA
