Sharp R-1480 - Parts and Packaging; Parts List

37
R-1480
R-1481
R-1482
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
ELECTRIC PARTS
1- 1 FH-DZB012MRY0 M High voltage rectifier assembly 1 AK
1- 2 RC-QZA173WRE0 M High voltage capacitor 1 AR
1- 3 QFS-TA013WRE0 M Temperature fuse 150˚C (Magnetron) 1 AG
1- 4 RMOTDA182WRE0 M Turntable motor 1 AQ
1- 5 RMOTDA214WRE0 M Stirrer motor 1 AQ
1- 6 RTHM-B005MRE0 M Thermal cut-out N.O. 60˚C (Hood Fan) 1 AG
1- 7 RTRN-B055MRE0 M Power transformer 1 BE
1- 8 RV-MZA280WRE0 M Magnetron 1 BD
1- 9 QFSHDB003MRE0 M Fuse holder 1 AD
1-10 QSW-MA110WRE0 M Secondary interlock and door sensing switches 2 AE
1-11 FFS-BA016/KIT M Monitor switch with fuse assembly 1 AF
1-12 FACCDB011MRE0 M Power supply cord 1 AP
1-13 QSOCLB006MRE0 M Oven lamp socket 3 AE
1-14 FMOTEA366WRK0 M Hood fan motor 1 BE
1-15 RMOTEA346WRE0 M Fan motor 1 AR
1-16 RLMPTA071WRE0 M Oven lamp 3 AG
1-17 RTHM-A080WRE0 M Thermal cut-out 145˚C (Cavity) 1 AG
CABINET PARTS
2- 1 LSTY-B021MRP0 M Rear stay 1 AF
2- 2 PDIF-B018MRF0 M Hood exhaust louver [R-1480] 1 AT
2- 2 PDIF-B019MRF0 M Hood exhaust louver [R-1481] 1 AT
2- 2 PDIF-B020MRF0 M Hood exhaust louver [R-1482] 1 AT
2- 3 GDAI-B045MRP0 M Right base plate 1 AM
2- 4 PCUSUB040MRP0 M Base cover cushion 1 AA
2- 5 GCABUB084MRP0 M Outer case cabinet [R-1480] 1 BA
2- 5 GCABUB085MRP0 M Outer case cabinet [R-1481] 1 BB
2- 5 GCABUB086MRP0 M Outer case cabinet [R-1482] 1 BC
2- 6 TMAPCB052MRR0 M Schematic diagram 1 AB
2- 7 FANGKB009MRY0 M Hood lamp glass assembly [R-1480] 1 AN
2- 7 FANGKB010MRY0 M Hood lamp glass assembly [R-1481] 1 AM
2- 7 FANGKB011MRY0 M Hood lamp glass assembly [R-1482] 1 AM
2-7-1 LANGQB016MRP0 M Hood lamp glass angle [R-1480] 1 AG
2-7-1 LANGQB020MRP0 M Hood lamp glass angle [R-1481] 1 AG
2-7-1 LANGQB027MRP0 M Hood lamp glass angle [R-1482] 1 AG
2-7-2 PGLSPB004MRE0 M Hood lamp glass 1 AH
2- 8 PCOVPB064MRt0 M Base cover [R-1480] 1 AY
2- 8 PCOVPB066MRt0 M Base cover [R-1481] 1 AY
2- 8 PCOVPB067MRt0 M Base cover [R-1482] 1 AY
CONTROL PANEL PARTS
3- 1 DPWBFB081MRU0 M Control unit 1 BL
3- 1A QCNCMA447DRE0 M 4-pin connector CN-A 1 AA
3- 1B QCNCMA448DRE0 M 5-pin connector CN-B 1 AA
3- 1C QCNCMA275DRE0 J 2-pin connector CN-E 1 AB
3- 1D QCNCWA030DRE0 J 12-pin connector CN-G 1 AE
3- 1E RV-KXB004MRE0 M Fluorescent display tube 1 AS
3- 1F PTPEHB010MRE0 M Tape 2mm 1 AB
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C5 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C6 VCEAB31VW106M J Capacitor 10 uF 35V 1 AB
C7-8 VCKYD11CY103N J Capacitor 0.01 uF 16V 2 AH
C9-10 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 2 AB
C20 VCEAB31VW106M J Capacitor 10 uF 35V 1 AB
C21 VCEAB31HW104M J Capacitor 0.1 uF 50V 1 AM
C30 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AH
C70-73 VCKYD11HB331K J Capacitor 330 pF 50V 4 AA
C100 RC-QZB014MRE0 M Capacitor 7 uF 230V 1 AK
C110 RC-QZB019MRE0 M Capacitor 0.033 uF 250V 1 AC
CF1 RCRS-A010DRE0 J Ceramic resonator (CST4.00MGW) 1 AD
D1-4 VHD11ES1///-1 J Diode (11ES1) 4 AB
D20 VHD1SS270A/-1 J Diode (1SS270A) 1 AA
D25-28 VHD1SS270A/-1 J Diode (1SS270A) 4 AA
D30-31 VHD1SS270A/-1 J Diode (1SS270A) 2 AA
D71-77 VHD1SS270A/-1 J Diode (1SS270A) 7 AA
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
*
*
*
∆
*
