Sharp R-1490 User Manual

18
R-1490
R-1491
R-1492
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
D20 VHD1SS270A/-1 J Diode (1SS270A) 1 AA
D25-28 VHD1SS270A/-1 J Diode (1SS270A) 4 AA
D30-31 VHD1SS270A/-1 J Diode (1SS270A) 2 AA
D70-77 VHD1SS270A/-1 J Diode (1SS270A) 8 AA
IC1 RH-IZA877DRE0 J LSI 1 AP
IC2 RH-IZA495DRE0 J IC 1AL
Q1 VS2SB1238//-3 J Transistor (2SB1238) 1 AA
Q3 VSKRA101M//-3 J Transistor (KRA101M) 1 AB
Q4 VSDTA123ES/-3 J Transistor (DTA123ES) 1 AA
Q20 VSKRA101M//-3 J Transistor (KRA101M) 1 AB
Q24-26 VSKRA101M//-3 J Transistor (KRA101M) 3 AB
Q27 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
Q28 VSKRA101M//-3 J Transistor (KRA101M) 1 AB
Q30 VSKRA101M//-3 J Transistor (KRA101M) 1 AB
R1 VRD-B12HF432J J Resistor 4.3k ohm 1/2W 1 AH
R2 VRD-B12EF152J J Resistor 1.5k ohm 1/4W 1 AA
R3 VRS-B13AA681J J Resistor 680 ohm 1W 1 AA
R4 VRD-B12HF511J J Resistor 510 ohm 1/2W 1 AB
R7-8 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 2 AA
R10 VRD-B12HF3R3J J Resistor 3.3 ohm 1/2W 1 AH
R20 VRD-B12HF102J J Resistor 1k ohm 1/2W 1 AA
R30 VRD-B12EF153J J Resistor 15k ohm 1/4W 1 AA
R31 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 1 AA
R40 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
R70-73 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 4 AA
R76-83 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 8 AA
R91-93 VRD-B12EF104J J Resistor 100k ohm 1/4W 3 AA
R100 VRS-B13AA331J J Resistor 330 ohm 1W 1 AA
R110 VRS-A12HA470J J Resistor 47 ohm 1/2W 1 AH
RY1-2 RRLY-A113DRE0 M Relay (DU24D1-1PR(M)) 2 AG
RY3-4 RRLY-A080DRE0 J Relay (OJ-SH-124LM) 2 AG
RY5 RRLY-A112DRE0 M Relay (VE24HSE-K) 1 AH
SSR1 RH-SZA009DRE0 M Solid state relay 1 AG
SP40 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB014MRE0 M Transformer 1 AM
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
ZD1 VHEHZ6A3///-1 J Zener diode (HZ6A-3) 1 AC
ZD2 VHEHZ161///-1 J Zener diode (HZ16-1) 1 AA
ZD3 VHEHZ5C2///-1 J Zener diode (HZ5C-2) 1 AA
ZD4 VHEHZ4A2///-1 J Zener diode (HZ4A-2) 1 AA
3- 2 FPNLCB213MRK0 M Control panel sub. assembly [R-1490] 1 AZ
3- 2 FPNLCB214MRK0 M Control panel sub, assembly [R-1491] 1 AZ
3- 2 FPNLCB215MRK0 M Control panel sub, assembly [R-1492] 1 AZ
3- 2-1 FUNTKB161MRE0 M Key unit [R-1490] 1 AU
3- 2-1 FUNTKB162MRE0 M Key unit [R-1491] 1 AU
3- 2-1 FUNTKB163MRE0 M Key unit [R-1492] 1 AU
3- 2-2 GMADIB030MRF0 M Display window 1 AF
3- 3 XEPSD30P10XS0 M Screw; 3mm x 10mm 5 AB
OVEN PARTS
4- 1 FFTA-B003MRK0 M Exhaust damper assembly 1 AH
4- 2 FROLPB024MRK0 M Turntable support assembly 1 AK
4- 3 NTNT-A090WRE0 M Turntable tray 1 AN
4- 4 LANGKB010MRP0 M Capacitor holder 1 BB
4- 5 FCOVPB012MRY0 M Stirrer cover assembly 1 AK
4- 6 FFAN-B006MRK0 M Stirrer fan assembly 1 AL
4- 7 ************* M Oven cavity (Not replaceable part) 1 --
4- 8 PPACGB014MRF0 M Turntable motor packing 1 AA
4- 9 PHOK-B017MRF0 M Latch hook 1 AG
4-10 LANGTB036MRP0 M Unit mounting plate 1 AP
4-11 NFANPB001MRE0 M Fan blade 1 AC
4-12 LBSHC0037WRE0 M Cord bushing 1 AB
4-13 PCOVPB065MRP0 M Oven lamp cover 1 AD
4-14 PDUC-B077MRP0 M Hood intake duct 1 AG
4-15 PCUSUB039MRP0 M Hood intake duct cushion 2 AA
4-16 PFILWB005MRP0 M Lamp filter 1 AB
4-17 PSKR-B012MRP0 M Magnetron air guide 1 AB
4-18 LANGTB040MRP0 M Chassis support 2 AE
4-19 PDUC-B078MRF0 M Hood duct 1 AX
4-20 PCUSUB043MRP0 M Hood duct cushion 1 AB
4-21 LSTPPB031MRF0 M Door stopper 1 AC
4-22 PCUSUB045MRP0 M Cushion 1 AE
4-23 PCUSUB044MRP0 M Sensor cushion 3 AB
∆
∆

Sharp R-1490 Specifications

General

Brand	Sharp
Model	R-1490
Category	Microwave Oven
Language	English
