Sharp R-1505F - PARTS LIST; ELECTRIC PARTS; CABINET PARTS; CONTROL PANEL PARTS

37
R-1500
R-1501
R-1505
R-1506
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
ELECTRIC PARTS
1- 1 FH-DZB016MRY0 M High voltage rectifier assembly 1 AH
1- 2 RC-QZA234WRE0 M High voltage capacitor 1 AP
1- 3 QFS-TA013WRE0 M Temperature fuse 150˚C (Magnetron) 1 AE
1- 4 RMOTDA211WRE0 M Turntable motor 1 AL
1- 5 RTHM-A070WRE0 M Thermal cut-out 145˚C (Cavity) 1 AF
1- 6 RTHM-0044MRE0 M Thermal cut-out N.O. 60˚C (Hood Fan) 1 AH
1- 7 RTRN-B068MRE0 M Power transformer 1 BC
1- 8 RV-MZA288WRE0 M Magnetron 1 BK
1- 9 QFSHDB003MRE0 M Fuse holder 1 AD
1-10 QSW-MA085WRE0 M Primary interlock and door sensing switches 2 AE
1-11 FFS-BA016/KIT M Monitor switch (V-16G-2C25) with fuse (20A) assembly 1 AF
1-12 FACCDB011MRE0 M Power supply cord 1 AQ
1-13 QSOCLB006MRE0 M Oven lamp socket 3 AE
1-14 FMOTEA441WRKZ M Hood fan motor 1 BC
1-15 RMOTEA406WRZZ M Fan motor 1 AT
1-16 RLMPTA068WRE0 M Oven lamp 3 AE
CABINET PARTS
2- 1 LSTY-B024MRP0 M Rear stay 1 AE
2- 2 PDIF-B030MRF0 M Hood exhaust louver [R-1500] 1 AQ
2- 2 PDIF-B031MRF0 M Hood exhaust louver [R-1501] 1 AQ
2- 2 PDIF-B030MRF0 M Hood exhaust louver [R-1505] 1 AQ
2- 2 PDIF-B031MRF0 M Hood exhaust louver [R-1506] 1 AQ
2- 3 GDAI-B065MRP0A M Base plate R 1 AG
2- 4 HDECQB027MRF0 M Front panel L [R-1500] 1 AL
2- 4 HDECQB028MRF0 M Front panel L [R-1501] 1 AL
2- 4 HDECQB027MRF0 M Front panel L [R-1505] 1 AL
2- 4 HDECQB028MRF0 M Front panel L [R-1506] 1 AL
2- 5 GCABUB103MRP0 M Outer case cabinet [R-1500] 1 AZ
2- 5 GCABUB105MRP0 M Outer case cabinet [R-1501] 1 AZ
2- 5 GCABUB103MRP0 M Outer case cabinet [R-1505] 1 AZ
2- 5 GCABUB105MRP0 M Outer case cabinet [R-1506] 1 AZ
2- 6 TMAPCB067MRR0 M Schematic diagram 1 AB
2- 7 FANGKB009MRY0 M Hood lamp glass assembly [R-1500] 1 AN
2- 7 FANGKB010MRY0 M Hood lamp glass assembly [R-1501] 1 AM
2- 7 FANGKB009MRY0 M Hood lamp glass assembly [R-1505] 1 AN
2- 7 FANGKB010MRY0 M Hood lamp glass assembly [R-1506] 1 AM
2-7-1 LANGQB016MRP0 M Hood lamp glass angle [R-1500] 1 AG
2-7-1 LANGQB020MRP0 M Hood lamp glass angle [R-1501] 1 AG
2-7-1 LANGQB016MRP0 M Hood lamp glass angle [R-1505] 1 AG
2-7-1 LANGQB020MRP0 M Hood lamp glass angle [R-1506] 1 AG
2-7-2 PGLSPB004MRE0 M Hood lamp glass 1 AH
2- 8 PCOVPB096MRT0 M Base cover [R-1500] 1 AV
2- 8 PCOVPB097MRT0 M Base cover [R-1501] 1 AV
2- 8 PCOVPB096MRT0 M Base cover [R-1505] 1 AV
2- 8 PCOVPB097MRT0 M Base cover [R-1506] 1 AV
CONTROL PANEL PARTS
3- 1 CPWBFB060MRU0 M Control unit 1 BF
3- 1A QCNCMA017JDZZ M 3-pin connector CN-A 1 AA
3- 1B QCNCMA448DRE0 M 5-pin connector CN-B 1 AA
3- 1C QCNCMA275DRE0 J 2-pin connector CN-E 1 AB
3- 1D FW-VZB189MRE0 M Lead wire harness CN-C 1 AB
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C21 VCEAB31VW106M J Capacitor 10 uF 35V 1 AB
C100 RC-QZB014MRE0 M Capacitor 7 uF 230V 1 AK
D1-4 RH-DZA006PRE0 J Diode (1N4002) 4 AD
D20-26 VHD1SS270A/-1 J Diode (1SS270A) 7 AA
D40 VHD1SS270A/-1 J Diode (1SS270A) 1 AA
Q21 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
R1-2 VRS-B13AA751J J Resistor 750 ohm 1W 2 AB
R30 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
RY1-2 RRLY-A113DRE0 M Relay (DU24D1-1PR(M)) 2 AG
RY3 RRLY-A123DRZZ M Relay (G5S-1 24V) 1 AG
RY4-6 RRLY-B004MRE0 M Relay (FTR-F3AA024E) 3 AG
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
*
*
*
∆
*
