CONTROL PANEL
1 Digital Display
2 Indicators
The appropriate indicator will flash or light up, just
above each symbol according to the instruction.
When an indicator is flashing, press the suitable
button (having the same symbol) or do the
necessary operation.
Microwave power level
Cooking in progress
3 +1min button
4 MICROWAVE POWER LEVEL button
5 STOP button
6 START button
7 TIMER knob
PART NAMES
OVEN
1 Control panel
2 Door lock openings
3 Oven lamp
4 Ceramic floor (Not removal)
5 Door hinges
6 Door
7 Door open handle
8 Safety door latches
9 Door seals and sealing surfaces
10 Cavity face plate
11 Air ventilation cover and openings
12 Power supply cord
13 Air intake filter (Air intake openings)
14 Outer cabinet
CONTROL PANEL
