Sharp R-1870 - Oven and Cabinet Parts Diagram; Component Location Illustration

14
R-1870
R-1871
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
4-14 PHOK-B013MRF0 M Latch hook 1 AG
4-15 FANGTB003MRY0 M Unit mounting plate 1 AV
4-16 PFPF-B002MRE0 M Heat protect L 1 AK
4-17 PPIPFB002MRE0 M Coller 1 AD
4-18 PREFHB006MRP0 M Heater cover L 1 AM
4-19 PDUC-B083MRP0 M Hood intake duct L 1 AG
4-20 NFANPB005MRK0 M Fan blade 1 AC
4-21 GBDYRB002MRP0 M Back plate 1 AX
4-22 FDUC-B046MRK0 M Fan duct 1 AM
4-23 LBSHC0037WRE0 M Cord bushing 1 AB
4-24 FDUC-B050MRK0 M Exhaust duct 1 AK
4-25 MLEVPB016MRF0 M Open lever 1 AD
4-26 PCUSGB030MRP0 M Cushion 1 AC
4-27 MCAMPB001MRF0 M Damper cam 1 AC
4-28 PCUSGB032MRP0 M Damper cushion 1 AC
4-29 PFPF-B001MRE0 M Heat protect R 1 AD
4-30 PFTA-B003MRP0 M Damper plate 1 AD
4-31 PREFHB004MRP0 M Thermal cover R 1 AK
4-32 LANGQB033MRP0 M Hood lamp angle 1 AM
4-33 PREFHB005MRP0 M Thermal cover bottom 1 AK
4-34 LSTPPB024MRF0 M Door stopper 1 AD
4-35 PCOVPB047MRP0 M Oven lamp cover 1 AD
4-36 PCOVPB050MRP0 M Heat protect top sheet 1 AK
4-37 PCUSGB027MRP0 M Cushion 1 AA
4-38 PDUC-B056MRF0A M Hood exhaust duct 1 AY
4-39 PDUC-B057MRP0 M Top duct 1 AN
4-40 PDUC-B058MRF0 M Magnetron duct 1 AD
4-41 PDUC-B060MRP0 M Hood intake duct R 1 AH
4-42 PFILWA035WRE0 M Oven light screen 1 AF
4-43 PFPF-B003MRE0 M Heat protect top 1 AE
4-44 PCUSUB018MRP0 M Exhaust cushion A 1 AA
4-45 PCUSUB019MRP0 M Exhaust cushion B 1 AA
4-46 PCUSUB020MRP0 M Cushion 1 AA
4-47 PCUSUB024MRP0 M Cushion 1 AD
4-48 PCUSGB035MRP0 M Cushion 2 AA
4-49 PCUSUB046MRP0 M Cushion 2 AA
4-50 PCUSUB047MRP0 M Cushion 1 AA
4-51 PFPF-B004MRE0 M Heat protect rear 1 AE
4-52 PFPF-B005MRE0 M Heat protect bottom 1 AE
DOOR PARTS
5 CDORFB285MRK0 M Door assembly, complete [R-1870] 1 BL
5 CDORFB286MRK0 M Door assembly, complete [R-1871] 1 BN
5- 1 DDORFB074MRY0 M Door panel assembly 1 BB
5- 2 GWAKPB140MRF0 M Door frame [R-1870] 1 AS
5- 2 GWAKPB141MRF0 M Door frame [R-1871] 1 AS
5- 3 PGLSPB036MRR0 M Door glass front [R-1870] 1 AV
5- 3 PGLSPB037MRR0 M Door glass front [R-1871] 1 AV
5- 4 GCOVHB031MRF0 M Choke cover 1 AM
5- 5 LSTPPB025MRF0 M Latch head 1 AE
5- 6 LSTPPB028MRF0 M Glass stopper 1 AD
5- 7 MSPRTA046WRE0 M Latch spring 1 AB
5- 8 PCUSUB022MRP0 M Cushion 1 AC
5- 9 XCTSD40P08000 M Screw : 4mm x 8mm 6 AA
MISCELLANEOUS
6- 1 CFZK-B131MRK0 M Installation material assembly 1 AN
6-1-1 LBSHC0040MRE0 M Grommet 1 AC
6-1-2 LX-BZ0195WRE0 M Toggle screw 4 AC
6-1-3 LX-MZ0001WRE0 M Cord holder 1 AC
6-1-4 XBRSD50P60000 M Screw : 5mm x 60mm 2 AC
6-1-5 XOTSD40P12000 M Screw : 4mm x 12mm 1 AA
6-1-6 XTSSD50P35000 M Screw : 5mm x 35mm 6 AA
6-1-7 XWHSD50-16300 M Washer 2 AA
6- 2 TINSEB141MRR0 M Installation instruction 1 AD
6- 3 TINSEB286MRK0 M Operation manual 1 AF
6- 4 TINSKB018MRR0 M Top template 1 AD
6- 5 TINSKB019MRR0 M Wall template 1 AD
6- 6 QW-QZB011MRE0 M High voltage wire A 1 AD
6- 7 TCADCB012MRR0 M Cook book 1 AP
6- 8 FW-VZB166MRE0 M Main harness A 1 AY
6- 9 UAMI-B011MRM0 M High rack 1 AQ
6-10 UAMI-B010MRM0 M Low rack 1 AP
