15
R-1870
R-1871
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authrized SHARP parts Distributor for your area.
Defective parts required return should be returned as indicated in the Service Policy.
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
6-11 FW-VZB077MRE0 M Main harness C 1 AH
6-12 TCAUAA041WRR0 M Caution label 1 AA
6-13 TCAUAB005MRR0 M DHHS caution label 1 AA
6-14 TCAUAB037MRR0 M Monitor caution label 1 AA
SCREWS,NUTS AND WASHERS
7- 1 LX-BZA041WRE0 M Screw : 4mm x 8mm 1 AA
7- 2 XOTSF40P10000 M Screw : 4mm x 10mm [R-1870] 3 AB
7- 2 XOTSE40P10000 M Screw : 4mm x 10mm [R-1871] 3 AC
7- 3 XCBSD30P08000 M Screw : 3mm x 8mm 3 AA
7- 4 XBTSD40P08RV0 M Screw : 3mm x 6mm 2 AA
7- 5 XCBSD30P08000 M Screw : 3mm x 8mm 2 AA
7- 6 XBTWW40P06000 M Screw : 4mm x 6mm 2 AA
7- 7 XOTSD40P12000 M Screw : 4mm x 12mm 19 AA
7- 8 XOTSF40P10000 M Screw : 4mm x 10mm [R-1870] 1 AA
7- 8 XOTSC40P10000 M Screw : 4mm x 10mm [R-1871] 1 AA
7- 9 LX-BZ0208WRE0 M Screw : 4mm x 8mm 2 AA
7-10 LX-BZB011MRE0 M Unit mounting screw 2 AH
7-11 LX-CZA038WRE0 M Special screw 4 AA
7-12 XCBWW30P08000 M Screw : 3mm x 6mm 5 AA
7-13 LX-CZ0052WRE0 M Special screw 2 AA
7-14 XCTWW40P08RV0 M Screw : 4mm x 8mm 2 AA
7-15 XRESD40-06000 M E-ring 1 AA
7-16 XOTSD40P12000 M Screw : 4mm x 12mm 2 AC
7-17 XCTWW40P08000 M Screw : 4mm x 8mm 2 AA
7-18 LX-NZA002WRE0 M Nut: 4mm x 3.2mm 1 AB
7-19 XWSUW40-10000 M Spring Washer 1 AA
7-20 LX-BZ0081YBE0 M Screw : 4mm x 8mm 9 AA
7-21 XWHSD50-20120 M Washer : 5mm x 2mm 1 AA
7-22 XWHUW40-08120 M Washer : 4mm x 0.8mm 2 AA
7-23 XWHUW50-08120 M Washer : 5mm x 0.8mm 1 AA
7-24 XOTSD40P08000 M Screw : 4mm x 8mm 13 AA
7-25 XOTWW40P10000 M Screw : 4mm x 10mm 8 AA
7-26 LX-CZB004MRE0 M Hood louver screws [R-1870] 2 AA
7-26 LX-CZB016MRE0 M Hood louver screws [R-1871] 2 AA
To Next Page
