R-1871-T
R-1872-T
R-1874-T
R-1875-T
REF. NO. PART NO. DESCRIPTION Q'TY CODE
MISCELLANEOUS
6- 1 CFZK-B659WRKZ Installation material assembly 1 AW
6-1-1 LBSHC0040MRE0 Grommet 1 AF
6-1-2 LX-BZ0195WRE0 Toggle screw 4 AH
6-1-3 XBRS750P60000 Screw : 5mm x 60mm 2 AK
6-1-4 XOTS740P12000 Screw : 4mm x 12mm 1 AB
6-1-5 XTSS750P35000 Screw : 5mm x 35mm 6 AD
6-1-6 XWHS750-16300 Washer 2 AG
6- 2 TINSEB235WRRZ Installation instruction 1 AR
6- 3 TINSEB236WRRZ Operation manual (R-1871-T/R-1872-T) 1 AR
6- 3 TINSEB240WRRZ Operation manual (R-1874-T/R-1875-T) 1 AR
6- 4 TINSKA031WRRZ Top template 1 AK
6- 5 TINSKA032WRRZ Wall template 1 AK
6- 6 QW-QZB011MRE0 High voltage wire A 1 AF
6- 7 TCADCB020WRRZ Cook book 1 AR
6- 8 FW-VZC282WREZ Main harness (R-1871-T/R-1872-T) 1 BG
6- 8 FW-VZC284WREZ Main harness (R-1874-T/R-1875-T) 1 BH
6- 9 FAMI-B006MRM0 High rack 1 AU
6-10 FAMI-B005MRM0 Low rack 1 AU
6-11 TCAUAA304WRRZ User caution label (R-1874-T/R-1875-T) 1 AC
6-12 TCAUAA382WRRZ Caution label 1 AF
6-13 TCAUAA302WRRZ DHHS caution label (R-1871-T/R-1872-T) 1 AF
6-13 TCAUAA307WRRZ DHHS caution label (R-1874-T/R-1875-T) 1 AD
6-14 TCAUAA300WRRZ NHW caution label (R-1871-T/R-1872-T) 1 AF
6-14 TCAUAA305WRRZ NHW caution label (R-1874-T/R-1875-T) 1 AD
6-15 TCAUAA301WRRZ Monitor caution label (R-1871-T/R-1872-T) 1 AF
6-15 TCAUAA366WRRZ Monitor caution label (R-1874-T/R-1875-T) 1 AF
SCREWS,NUTS AND WASHERS
7- 1 XHPS740P08K00 Screw 5 AC
7- 2 XOTS740P08000 Screw (R-1871-T/R-1872-T) 4 AB
7- 2 XOTS840P08000 Screw (R-1874-T/R-1875-T) 4 AB
7- 3 XHPS730P08000 Screw 6 AC
7- 4 XBTS740P08RV0 Screw 2 AD
7- 5 XCTWW40P08000 Screw 1 AB
7- 6 XBTWW40P06000 Screw 2 AA
7- 7 XOTS740P08000 Screw 24 AB
7- 8 XHTS740P08000 Screw 1 AC
7- 9 XHTS740P08RV0 Screw 2 AG
7-10 LX-BZB011MRE0 Unit mounting screw 2 AT
7-11 LX-CZB024MRE0 Hood louver Screws (R-1871-T/R-1872-T) 2 AE
7-11 LX-CZB025MRE0 Hood louver Screws (R-1874-T/R-1875-T) 2 AE
7-12 XCBWW30P06000 Screw 5 AB
7-13 LX-CZ0052WRE0 Special screw 2 AA
7-14 XOTWW40P08000 Screw 19 AB
