R209KK
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
1-1 QSW-MA085WRE0 AF
Secondary interlock switch/ Door sensing switch
1-1 QSW-MA137WRE0 AH
Secondary interlock switch/ Door sensing switch (Interchangeable)
1-1 QSW-MA147WRE0 AG
Secondary interlock switch/ Door sensing switch (Interchangeable)
1-2 FFS-BA026WRKZ AN
Monitor fuse (15A) and monitor switch assembly (SwitchAM51620C53Y1)
1-3 FACCDA107WREZ AU
Power supply cord
1-3 FACCDA108WREZ --
Power supply cord (Interchangeable) (for production use)
!
1-4 FH-DZA114WRKZ AR
High voltage rectifier assy
!
1-5 RC-QZA327WRZZ AT
High voltage capacitor
!
1-5 RC-QZA328WRZZ AS
High voltage capacitor (Interchangeable)
!
1-5 RC-PZA041WRE0 AS
High voltage capacitor (Interchangeable)
!
1-5 RC-QZA307WRZZ AX
High voltage capacitor (Interchangeable)
1-6 RMOTEA433WRZZ AX
Fan motor
1-6 RMOTEA346WRE0 AV
Fan motor (Interchangeable)
1-6 RMOTEA356WRE0 --
Fan motor (Interchangeable) for production use
!
*
1-7 RV-MZA338WRZZ BH
Magnetron
!
*
1-7 RV-MZA339WRZZ --
Magnetron (Interchangeable) for production use
1-8 RLMPTA087WRZZ AL
Oven lamp
1-8 RLMPTA082WRZZ AL
Oven lamp (Interchangeable)
1-8 RLMPTA085WRZZ AL
Oven lamp (Interchangeable)
1-9 RMOTDA264WRZZ AT
Turntable motor
1-9 RMOTDA252WRZZ AN
Turntable motor (Interchangeable)
1-9 RMOTDA186WRE0 AW
Turntable motor (Interchangeable)
1-10 QFS-TA014WRE0 AG
Temperature fuse 150C (Oven)
1-10 RTHM-A075WRE0 AN
Thermal cut-out 145C (Oven) (Interchangeable)
1-10 RTHM-A119WRE0 AK
Thermal cut-out 145C (Oven) (Interchangeable)
!
1-11 RTRN-A727WRZZ BF
Power trnasformer
!
1-11 RTRN-A728WRZZ BF
Power transformer (Interchangeable) for production
1-12 FPWBFA385WRKZ AV
Noise filter
CABINET PARTS
2-1 GCABUA960WRPZ BE
Outer case cabinet
2-2 GDAI-A377WRWZ AS
Bottom plate
2-3 GLEGPA104WREZ AF
Foot
OVENPARTS
*
4-1 PHOK-A144WRFZ AL
Latch hook
4-2 LBNDKA168WRPZ AD
Capacitor holder
4-3 NFANJA053WRFZ AG
Fan blade
4-4 PDUC-A908WRWZ AR
Fan duct
*
4-5 ************* --
Oven cavity (Not replaceable part)
4-6 LANGFA267WRPZ AH
Chassis support
4-7 MLEVPA241WRFZ AG
Switch lever
4-8 PCOVPA419WREZ AG
Waveguide cover
4-9 PDUC-A909WRPZ AN
Air duct
4-10 PPACGA176WREZ AC
TTM packing
4-11 PCUSUA501WRP0 AB
Cushion
4-12 PCUSGA662WRP0 AD
Cushion B
4-13 PCUSGA661WRP0 AD
Cushion A
4-14 PCUSGA615WRPZ AE
Cushion
MISCELLANEOUS
6-1 NTNT-A034WRF0 AM
Turntable
6-2 FROLPA101WRKZ AR
Turntable support
6-3 TCAUAA291WRRZ AE
Monitor caution
6-4 TCAUAA268WRRZ AF
DHHS caution label
SCREWS,NUTS AND WASHERS
7-1 XHPSD40P08K00 AC
screw : 4mm x 8mm
7-2 XHTSD40P08RV0 AA
Screw : 4mm x 8mm
7-3 LX-CZA070WRE0 AC
Special screw (Torx tamper pfoof screw)
7-4 LX-CZ0052WRE0 AA
Special screw
7-5 LX-EZA042WRE0 AB
Special screw
7-6 LX-CZA073WRE0 AC
Special screw
7-7 XHPSD40P08000 AA
Screw : 4mm x 8mm
7-8 XOTSD40P08000 AA
Screw : 4mm x 8mm
7-9 XOTSF40P08000 AA
Screw : 4mm x 8mm
