R209KK
5
NO.
P
ARTS CODE
PRICE
RANK
NEW
MARK
PA
R
T
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PA
RTS
CONTROL PANEL PARTS
3-1
FPNLCB
856WRKZ
BA
Control panel frame with ke
y unit
3-1-1
PSHEPB107WREZ
AT
Graphic sheet
3-1-2
QSW-KA053DRZZ
AQ
Membrane switch
3-2
JBTN-B
309WRFZ
AG
Open button
3-3
MSPRCA
050WRE0
AB
Open button spring
3-4
DPWBFC
479WRUZ
BH
Control unit
3-5
QCNC-A
014WRZZ
AE
Rubber connector
3-6
RLCDSA
105DRZZ
AQ
Liquid crystal display
3-7
XEPSD3
0P08XS0
AA
Screw; 3mm x 8mm
3-8
PCUSUA
633WREZ
AE
Cushion
DOORPARTS
*
5-1
FDORFA
397WRTZ
BB
Door panel assembly
*
5-2
GWAKPA
980WRRZ
AW
Door frame
5-3
HPNL-A
835WRRZ
AS
Door screen
*
5-4
LSTPPA
205WRFZ
AF
Latch head
5-5
MSPRTA
187WRE0
AC
Spring
5-6
PSHEPA
782WREZ
AG
Sealer film
*
5-7
GCOVHA
424WRFZ
AK
Choke cover
MISCELLANEOUS
6-5
TINSEB
076WRRZ
AM
Instruction book
6-6
FW-VZC
044WREZ
AQ
Main wire harness
38
40
Table of Contents
Default Chapter
2
Table of Contents
2
Precautions to be Observed before and During Servicing to Avoid Possible Expo
3
After Repairing
4
When the Testing Is Completed
4
Before Servicing
3
CHAPTER 2. MICROWAVE MEASUREMENT PRO- CEDURE Requirements
5
Preparation for Testing
5
Leakage Test
5
Chapter 1 Warning
6
Danger
6
Chapter 3. Foreword and Warning Foreword
6
Chapter 4. Product Description
7
Specifications
7
Chapter 5. General Information Grounding Instructions
8
Oven Diagram
8
Chapter 6. Operation Description of Operating Se- Quence
10
Oven Schenatic
11
Description and Function of Components
12
Chapter 7. Troubleshooting Guide
13
Troubleshooting Chart
13
CHAPTER 8. TEST PROCEDURES Procedure a : MAGNETRON ASSEMBLY TEST
14
Procedure B : POWER TRANSFORMER TEST
14
Procedure C : HIGH VOLTAGE RECTIFIER TEST
14
Procedure D : HIGH VOLTAGE CAPACITOR TEST
15
Procedure E : THERMAL CUT-OUT (OVEN) TEST
15
Procedure E : TEMPERATURE FUSE (OVEN) TEST
15
Procedure F : SECONDARY INTERLOCK SWITCH TEST
15
Procedure F : PRIMARY INTERLOCK SYSTEM TEST
16
Procedure G : MONITOR SWITCH TEST
16
Procedure H : BLOWN MINITOR FUSE TEST
16
Procedure I : NOISE FILTER TEST
17
Procedure J : TOUCH CONTROL PANEL ASSEMBLY TEST
17
Procedure K : KEY UNIT TEST
18
Procedure L : RELAY TEST
19
Procedure M : DEFROST TEST
19
Procedure N : FOIL PATTERN on the PRINTED WIRING BOARD TEST
19
Chapter 9. Touch Control Panel Assem
21
Outline of Touch Control Panel
21
Description of Lsi
21
Servicing for Touch Control Panel
23
Chapter 10. Precautions for Using Lead- Free Solder
24
Employing Lead-Free Solder
24
Using Lead-Free Wire Solder
24
Soldering
24
Chapter 11. Component Replacement and
25
Warnings
25
Outer Case Removal
26
Magnetron Removal
26
High Voltage Components Removal (High Voltage Capacitor and High Voltage Rectifier Assembly)
26
Power Transformer Removal
26
Positive Lock Connector (No-Case Type) Removal
27
Control Panel Assembly Removal
27
Graphic Sheet and Membrane Switch Replacement
27
Power Supply Cord Replacement
28
Turntable Motor Removal
28
Cooling Fan Motor Removal
28
Door Sensing Switch/Secondary Interlock Switch and Monitor Switch Removal
29
Door Sensing Switch/Secondary Interlock Switch and Monitor Switch Adjustment
29
Door Replacement
30
Chapter 12. Circuit Diagrams
32
Pictorial Diagram (Figure S-1)
32
Control Panel Circuit (Figure S-2)
33
Printed Wiring Board (Figure S-3)
34
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Sharp R-209KK and is the answer not in the manual?
Ask a question
Sharp R-209KK Specifications
General
Brand
Sharp
Model
R-209KK
Category
Microwave Oven
Language
English
Related product manuals
Sharp Carousel R-209K
24 pages
Sharp R-209
43 pages
Sharp R-209BK
40 pages
Sharp R-209FW
16 pages
Sharp R-209HK
36 pages
Sharp R-209VN
31 pages
Sharp R-209FK
16 pages
Sharp R-209HW
36 pages
Sharp R-209EKA
12 pages
Sharp R-200K
24 pages
Sharp R-202EK
12 pages
Sharp R-200J Series
16 pages
