Sharp R-290H Service Manual

R-290H(S)
30
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
REF. NO. PART NO. DESCRIPTION Q'TY CODE
6- 2 FROLPA101WRKZ Turntable support 1 AR
6- 3 TCAUHA214WRR0 K caution label 1 AC
6- 4 FW-VZB889WREZ Main wire harness 1 AV
6- 5 TINSEA964WRRZ Instruction book 1 AM
6- 6 FW-VZB888WREZ Switch harness 1 AU
6- 7 TSPCND300WRRZ Rating label 1 AF
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 screw : 4 mm x 8 mm 5 AC
7- 2 XHTSD40P08RV0 Screw : 4mm x 8mm 5 AA
7- 3 XOTSD40P08000 Screw : 4mm x 8mm 10 AA
7- 4 LX-CZ0052WRE0 Special screw 2 AA
7- 5 LX-EZA042WRE0 Special screw 2 AB
7- 6 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7- 7 XHPSD40P08000 Screw : 4mm x 8mm 3 AA
7- 8 XOTSD40P12RV0 Screw : 4mm x 12mm 2 AA
7- 9 XOTSE40P08000 Screw : 4mm x 8mm 2 AA
