Sharp R-310BK User Manual

33
R-310BK
R-310BW
REF. NO. PART NO. DESCRIPTION Q'TY CODE
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 3. PART NO.
2. REF. NO. 4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts required return should be returned as indicated in the Service Policy.
4- 6 PDUC-A652WRP0 Fan duct 1 AU
4- 7 ************* Oven cavity (Not a replaceable part) 1--
4- 8 LANGFA175WRP0 Chassis support 1 AX
4- 9 LANGQA452WRP0 Partition angle 1 AK
4-10 LANGQA492WRP0 MG thermo angle 1 AV
4-11 MLEVPA226WRF0 Switch lever 1 AF
4-12 NCPL-A045WRF0 Coupling 1 AH
4-13 PCUSGA399WRE0 Cushion 1 AF
4-14 PCOVPA275WRE0 Waveguide cover 1 AR
4-15 PCUSGA339WRP0 Cushion 1 AG
4-16 PCUSUA212WRP0 Cushion 1 AB
4-17 PCUSUA235WRP0 Cushion 1 AF
4-18 GCOVHA385WRF0 Choke cover 1 AG
4-19 PCUSGA385WRP0 Cushion 1 AH
4-20 PCUSUA126WRE0 Cushion 1 AC
4-21 PGIDHA058WRP0 MG air guide 1 AE
DOOR PARTS
5- 1 FDORFA318WRT0 Door panel 1 BE
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA458WRR0 Door frame [R-310BW] 1 AY
5- 3 GWAKPA448WRR0 Door frame [R-310BK] 1 AW
5- 4 HPNL-A663WRR0 Door screen [R-310BW] 1 AL
5- 4 HPNL-A662WRR0 Door screen [R-310BK] 1 AL
5- 5 LSTPPA139WRF0 Latch head 1 AF
5- 6 MSPRTA084WRE0 Latch spring 1 AB
5- 7 PCUSUA481WRP0 Cushion 1 AB
5- 8 PCUSUA452WRP0 Cushion [R-310BW] 1 AB
5- 8 PCUSUA452WRP0 Cushion [R-310BK] 2 AB
5- 9 XCPSD40P08000 Screw : 4mm x 8mm [R-310BW] 1 AA
5- 9 XCPSD40P08000 Screw : 4mm x 8mm [R-310BK] 2 AA
5-10 XCPSD40P08WN2 Screw : 4mm x 8mm 1 AC
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A079WRE0 Turntable tray 1 AR
6- 3 FW-VZB678WRE0 Main wire harness 1 AW
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA166WRR0 DHHS caution label 1 AC
6- 7 TCAUAA200WRR0 Monitor caution label 1 AB
6- 8 TINSEA755WRR0 Instruction book 1 AD
6- 9 TCAUAA240WRR0 Screw caution 1 AC
SCREWS,NUTS AND WASHERS
7- 1 XFPSD40P08K00 Screw : 4mm x 8mm 10 AA
7- 2 XHPSD30P06000 Screw : 3mm x 6mm 2 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 3 AA
7- 4 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 6 AA
7- 6 XOTSD40P12000 Screw : 4mm x 12mm 13 AA
7- 7 XOTSE40P08000 Screw : 4mm x 8mm [R-310BW] 1 AA
7- 7 XOTSF40P08000 Screw : 4mm x 8mm [R-310BK] 1 AA
∆
∆
∆
∆
∆
*
