16
R-330BK
R-330BW
WARNING : The oven should be fully assembled before following procedure.
(1) Place one cup of water in the center of the turntable tray in the oven cavity.
(2) Close the door, touch the " Compu Defrost " pad once and touch the Number pad "1", and touch the
Number pad 5. And then touch the "START" pad.
(3) The oven is in Compu Defrost cooking condition.
(4) The oven will operate as follows
WEIGHT
1ST STAGE 2ND STAGE 3RD STAGE
LEVEL TIME LEVEL TIME LEVEL TIME
0.5lbs 50% 37sec. 30% 1min.20sec. 10% 2min.15sec.
(5) If improper operation is indicated, the control unit is probably defective and should be checked.
5. Reconnect all leads removed from components during testing.
6. Re-install the outer case (cabinet).
7. Reconnect the power supply cord after the outer case is installed.
8. Run the oven and check all functions.
TEST PROCEDURES
PROCEDURE
LETTER
COMPONENT TEST
1. Disconnect the power supply cord, and then remove outer case.
2. Open the door and block it open.
3. Discharge high voltage capacitor.
4. Disconnect the leads to the primary of the power transformer.
5.
Ensure that these leads remain isolated from other components and oven chassis by using insulation tape.
6. After that procedure, re-connect the power supply cord.
7. Remove the outer case and check voltage between Pin No. 1 of the 2 pin connector (A) and the
common terminal of the relay RY1 on the control unit with an A.C. voltmeter.
The meter should indicate 120 volts, if not check oven circuit.
RY1 and RY2 Relay Test
These relays are operated by D.C. voltage
Check voltage at the relay coil with a D.C. voltmeter during the microwave cooking operation.
DC. voltage indicated ............... Defective relay.
DC. voltage not indicated ......... Check diode which is connected to the relay coil. If diode is good,
control unit is defective.
RELAY SYMBOL OPERATIONAL VOLTAGE CONNECTED COMPONENTS
RY1 Approx. 24.3V D.C. Oven lamp / Turntable motor / Cooling fan motor
RY2 Approx. 23.5V D.C. Power transformer
8. Disconnect the power supply cord, and then remove outer case.
9. Open the door and block it open.
10. Discharge high voltage capacitor.
11. Reconnect all leads removed from components during testing.
12. Re-install the outer case (cabinet).
13. Reconnect the power supply cord after the outer case is installed.
14. Run the oven and check all functions.
K RELAY TEST
L COMPU DEFROST TEST
5
4
3
21
09876
G 8 G 7 G 6 G 5 G 4 G 3 G 2 G 1
G12 G11 G10 G 9
Minute
Plus
Compu
Defrost
Fish /
seafood
Baked
potato
Custom
Help
Kitchen
Timer
Power
Level
Compu
Cook
Ground
meat
Frozen
snacks
Frozen
vegetables
Frozen
main dish
Fresh
vegetables
Beverage
Center
Clock Rice
Reheat Popcorn
Poultry
Start
Touch on
Stop
Clear
