38
R-330BK
R-330BW
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
∆
∆
∆
∆
∆
∆
*
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A652WRP0 Fan duct 1 AU
4- 7 ************* Oven cavity (Not a replaceable part) 1--
4- 8 LANGFA175WRP0 Chassis support 1 AX
4- 9 LANGQA452WRP0 Partition angle 1 AK
4-10 LANGQA492WRP0 MG thermo angle 1 AV
4-11 MLEVPA226WRF0 Switch lever 1 AF
4-12 NCPL-A045WRF0 Coupling 1 AH
4-13 PCUSGA399WRE0 Cushion 1 AF
4-14 PCOVPA275WRE0 Waveguide cover 1 AR
4-15 PCUSGA339WRP0 Cushion 1 AG
4-16 PCUSUA212WRP0 Cushion 1 AB
4-17 LANGTA338WRP0 Sensor mounting angle 1 AP
4-18 GCOVHA385WRF0 Choke cover 1 AG
4-19 PCUSGA385WRP0 Cushion 1 AH
4-20 PCUSUA192WRP0 Cushion 1 AD
4-21 PCUSUA329WRP0 Cushion 1 AC
4-22 PGIDHA058WRP0 MG air guide 1 AE
4-23 PCUSUA126WRP0 Cushion 1 AC
DOOR PARTS
5- 1 FDORFA318WRT0 Door panel 1 BE
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA547WRR0 Door frame [R-330BK] 1 AZ
5- 3 GWAKPA549WRR0 Door frame [R-330BW] 1 AZ
5- 4 HPNL-A684WRR0 Door screen [R-330BK] 1 AT
5- 4 HPNL-A690WRR0 Door screen [R-330BW] 1 AT
5- 5 LSTPPA139WRF0 Latch head 1 AF
5- 6 MSPRTA187WRE0 Latch spring 1 AC
5- 7 XCPSD40P08000 Screw : 4mm x 8mm 1 AA
5- 8 XCPSD40P08WN2 Screw : 4mm x 8mm 1 AC
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A079WRE0 Turntable tray 1 AR
6- 3 FW-VZB678WRE0 Main wire harness 1 AW
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA166WRR0 DHHS caution label 1 AC
6- 7 TCAUAA200WRR0 Monitor caution label 1 AB
6- 8 TINSEA742WRR0 Instruction book 1 AF
6- 9 TCAUAA240WRR0 Screw caution 1 AC
6-10 TLABMA559WRR0 Menu label 1
SCREWS,NUTS AND WASHERS
7- 1 XFPSD40P08K00 Screw : 4mm x 8mm 6 AA
7- 2 XHPSD30P06000 Screw : 3mm x 6mm 4 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 3 AA
7- 4 XFTSD40P08000 Screw : 4mm x 8mm 4 AA
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 7 AA
7- 6 XOTSD40P12000 Screw : 4mm x 12mm 13 AA
7- 7 XOTSF40P08000 Screw : 4mm x 8mm [R-330BK] 1 AA
7- 7 XOTSE40P08000 Screw : 4mm x 8mm [R-320BW] 1 AA
7- 8 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
