R403KKT
5
NO.
P
ARTS CODE
PRICE
RANK
NEW
MARK
PA
R
T
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PA
RTS
CONTROL PANEL PARTS
3-1
FPNLCB
889WRKZ
BA
Panel sub assembly
3-1-1
PSHEPB168WREZ
AT
Key sheet
3-1-2
QSW-KA063DRZZ
AQ
FPC
3-1-3
GMADIA157WRRZ
AL
Display window
3-2
JBTN-B
347WRFZ
AG
Open button
3-3
MSPRCA
157WREZ
AF
Open button spring
3-4
DPWBFC
531WRKZ
BK
Control unit
3-5
XEPS73
0P08XS0
AB
Screw; 3mm x 8mm
DOOR PARTS
*
5-1
FDORFA
412WRTZ
BF
Door panel
5-2
PSHEPA
336WRP0
AF
Sealer film
5-3
GWAKPB
020WRRZ
AX
Door frame
*
5-4
HPNL-A
858WREZ
AS
Door screen
*
5-5
GCOVHA
382WRF0
AM
Choke cover
*
5-6
LSTPPA
139WRF0
AE
Latch head
5-7
MSPRTA
084WRE0
AB
Latch spring
5-8
LSTPPA
167WRF0
AG
Door stopper
MISCELLANEOUS
6-5
FW-VZC
094WREZ
AS
Main wire harness
6-6
FW-VZC
093WREZ
AN
Filter harness
6-7
TINSEB
115WRRZ
AM
Instruction book
38
40
Table of Contents
Default Chapter
1
Microwave Oven
1
Sharp Corporation
1
Table of Contents
2
