R405KST
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1 DPNLCB972WRKZ BD Panel med assembly
3-1-1 FBTN-A158WRKZ AX Open button assembly
3-1-1-1 JBTN-B358WRFZ AK Open button
3-1-1-2 HDECQA299WRPZ AL Button decoration
3-1-2 HDECQA300WRPZ AT Panel decoration
3-1-3 MSPRCA157WREZ AF Open button spring
3-1-4 GMADIA158WRRZ AH Display window
3-1-5 PSHEPB178WREZ AT Key sheet
3-1-6 QSW-KA065DRZZ AQ FPC
3-2 DPWBFC531WRKZ BK Control unit
3-3 XEPS730P08XS0 AB Screw; 3mm x 8mm
DOOR PARTS
* 5-1 FDORFA412WRTZ BF Door panel
5-2 PSHEPA336WRP0 AF Sealer film
* 5-3 FWAKPA445WRKZ BF Door frame assembly
* 5-3-1 GWAKPB033WRFZ AX Door frame
5-3-2 HDECQA303WRPZ BA Door decoration
5-4 HPNL-A866WRRZ AR Door screen
* 5-5 GCOVHA382WRF0 AM Choke cover
* 5-6 LSTPPA139WRF0 AE Latch head
5-7 MSPRTA084WRE0 AB Latch spring
5-8 LSTPPA167WRF0 AG Door stopper
MISCELLANEOUS
6-5 FW-VZC094WREZ AS Main wire harness
6-6 FW-VZC093WREZ AN Filter harness
6-7 TINSEB118WRRZ AM Instruction book
To Next Page
