R410LW
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
1-1 FPWBFA417WRKZ AY Noise filter assembly
1-1 FPWBFA389WRKZ AW Noise filter assembly (Interchangeable)
1-2 FFS-BA033WRKZ -- Monitor fuse 20A and monitor switch(V-5220Q)
1-2 FFS-BA037WRKZ AN Monitor fuse 20A and monitor switch(D3V-1G-2C25) (Interchangeable)
1-3 QFS-TA013WRE0 AG Temp. fuse 150C (Magnetron)
1-4 QSW-MA085WRE0 AF Primary interlock switch/ door sensing switch
1-4 QSW-MA147WRZZ AG Primary interlock switch/ door sensing switch (Interchangeable)
!
*
1-5 RV-MZA346WRZZ BK Magnetron
1-6 RTHM-A119WRE0 AK Thermal cut-out 145C (Oven)
1-6 RTHM-A075WRE0 AN Thermal cut-out 145C (Oven)
1-6 RTHM-A134WRZZ AK Thermal cut-out 145C (Oven)
1-7 FACCDA083WRE0 AQ Power supply cord
1-7 FACCDA085WREZ AQ Power supply cord (Interchangeable)
1-7 FACCDA103WREZ AQ Power supply cord (Interchangeable)
!
1-8 FH-DZA118WRKZ AN H.V. rectifier assy
!
1-8 FH-DZA131WRKZ -- H.V. rectifier assembly for production use (Interchangeable)
!
1-9 RC-QZA211WRE0 AV High voltage capacitor
!
1-9 RC-QZA331WRZZ -- High voltage capacitor for production use (Interchangeable)
1-10 RMOTEA433WRZZ AX Fan motor
1-11 RLMPTA087WRZZ AL Oven lamp
1-11 RLMPTA082WRZZ AL Oven lamp (Interchangeable)
1-11 RLMPTA085WRZZ AL Oven lamp (Interchangeable)
1-12 RMOTDA264WRZZ AT Turntable motor
1-12 RMOTDA186WRE0 AW Turntable motor (Interchangeable)
1-13 RTRN-A746WRZZ BM Power transformer
1-13 RTRN-A745WRZZ -- Power transformer for production use (Interchangeable)
CABINET PARTS
2-1 GCABUA991WRPZ BH Outer case cabinet [R-410LK]
2-1 GCABUB012WRPZ BH Outer case cabinet [R-410LW]
2-2 GDAI-A403WRWZ BA Base plate
2-3 GLEGPA104WREZ AF Leg
OVEN PARTS
* 4-1 PHOK-A130WRFZ AK Latch hook
4-2 LBNDKA172WRPZ AM H.V. capacitor band
4-3 NFANJA053WRFZ AG Fan blade
4-4 LANGTA419WRPZ AT Chassis support
* 4-5 ************* -- Oven cavity (Not a replacement part)
4-6 MLEVPA244WRFZ AG Switch lever
4-7 PCOVPA311WRE0 AG Waveguide cover
4-8 PCUSGA532WRP0 AF Cushion
4-9 PCUSUA191WRP0 AC Cushion
4-10 PPACGA084WRF0 AE TTM packing
4-11 PCUSUA410WRP0 AB Cushion
4-12 PCUSUA455WRP0 AD Cushion
4-13 PDUC-A610WRF0 AR Fan duct
4-14 PDUC-A936WRFZ AV MG duct
4-15 PPACGA272WREZ AG Cushion
MISCELLANEOUS
6-1 FROLPA097WRKZ AN Roller assy
6-2 NTNT-A108WREZ AW Turntable
6-3 TCAUAA292WRRZ AE Monitor caution
6-4 TCAUAA296WRRZ AH DHHS caution label
SCREWS, NUTS AND WASHERS
7-1 XHPS740P08K00 AB Screw : 4mm x 8mm
7-2 LX-CZA070WRE0 AC Special screw (Torx tamper proof screw)
7-3 LX-CZ0052WRE0 AA Special screw
7-4 LX-EZA042WRE0 AB Special screw
7-5 LX-EZA050WRE0 AB Special screw
7-6 XHPS730P06000 AB Screw : 3mm x 6mm
7-7 XHPS740P08000 AB Screw : 4mm x 8mm
7-8 XHTS740P08RV0 AG Screw : 4mm x 8mm
7-9 XHTS740P12RV0 AC Screw : 4mm x 12mm
7-10 XOTS740P10000 AB Screw : 4mm x 10mm
