17
R-420EK
WARNING : The oven should be fully assembled before following procedure.
(1) Place one cup of water in the center of the turntable tray in the oven cavity.
(2) Close the door, touch the " steaks / chops " pad once.
(3) The oven is in Compu Defrost cooking condition.
(4) The oven will operate as follows
1ST STAGE 2ND STAGE
WEIGHT
LEVEL TIME LEVEL TIME
0.5lb 60% 25sec. 40% 20sec.
6. Re-install the outer case (cabinet).
7. Reconnect the power supply cord after the outer case is installed.
8. Run the oven and check all functions.
TEST PROCEDURES
PROCEDURE
LETTER
COMPONENT TEST
1. Disconnect the power supply cord, and then remove outer case.
2. Open the door and block it open.
3. Discharge high voltage capacitor.
4. Disconnect the leads to the primary of the power transformer.
5. Ensure that these leads remain isolated from other components and oven chassis by using insulation
tape.
6. After that procedure, re-connect the power supply cord.
7. Remove the outer case and check voltage between Pin No. 1 of the 2 pin connector (A) and the
common terminal of the relay RY1 on the control unit with an A.C. voltmeter.
The meter should indicate 120 volts, if not check oven circuit.
RY1 and RY2 Relay Test
These relays are operated by D.C. voltage
Check voltage at the relay coil with a D.C. voltmeter during the microwave cooking operation.
DC. voltage indicated ............. Defective relay.
DC. voltage not indicated ........ Check diode which is connected to the relay coil. If diode is good,
control unit is defective.
RELAY SYMBOL OPERATIONAL VOLTAGE CONNECTED COMPONENTS
RY1 Approx. 24.3V D.C. Oven lamp / Turntable motor / Cooling fan motor
RY2 Approx. 23.4.V D.C. Power transformer
8. Disconnect the power supply cord, and then remove outer case.
9. Open the door and block it open.
10. Discharge high voltage capacitor.
11. Reconnect all leads removed from components during testing.
12. Re-install the outer case (cabinet).
13. Reconnect the power supply cord after the outer case is installed.
14. Run the oven and check all functions.
L COMPU DEFROST TEST
Key Unit
K RELAY TEST
G 9
G10G11G12
G13
G14
G 8 G 7 G 6 G 5 G 4 G 3 G 2 G 1
CHICKEN
PIECES
STEAKS
CHOPS
RICE
MINUTE
PLUS
CHICKEN
BREAST
KEEP WARM
PLUS
POWER
LEVEL
CUSTOM
HELP
START
BEVERAGE
STOP
CLEAR
BAKED
POTATOES
POPCORN
FRESH
VEGETABLES
FROZEN
VEGETABLES
REHEAT
SENSOR
FISH
SEAFOOD
FROZEN
ENTREES
FROZEN
ROLLS
MUFFINS
FRESH
ROLLS
MUFFINS
GROUND MEAT
(SENSOR COOK)
GROUND MEAT
(COMPU DEFROST)
54321
09876
TIMER
CLOCK
