Sharp R-420EK User Manual

38
R-420EK
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
∆
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
∆
*
DOOR PARTS
5- 1 FCOV-B180MRK0 M Door frame assembly 1 AP
5-1-1 LSTPPB021MRF0 M Latch head 1 AE
5-1-2 MSPRTA046WRE0 M Latch spring 1 AB
5- 2 FDORFB062MRT0 M Door panel 1 AW
5- 3 PSHEPB021MRE0 M Sealer film 1 AE
5- 4 GCOVHB042MRF0 M Choke cover 1 AG
5- 5 HPNL-B092MRE0 M Door screen 1 AK
MISCELLANEOUS
6- 1 FW-VZB125MRE0 M Stop switch harnnes 1 AF
6- 2 FW-VZB168MRE0 M Main wire harnnes 1 AU
6- 3 TLABBB007MRE0 M Cavity hole cover 1 AA
6- 4 FROLPB025MRK0 M Turntable support 1 AN
6- 5 NTNT-A095WRE0 M Turntable tray 1 AM
6- 6 TCAUAB037MRR0 M Monitor caution label 1 AA
6- 7 TCAUAB038MRR0 M DHHS/Screw caution label 1 AB
6- 8 TINSEB269MRR0 M Operation manual 1 AD
6- 9 QW-QZB016MRE0 M High voltage wire A 1 AC
SCREWS,NUTS AND WASHERS
7- 1 LX-BZA041WRE0 M Special screw 5 AA
7- 2 LX-CZ0052WRE0 M Special screw 3 AA
7- 3 XHTSD40P12RV0 M Screw : 4mm x 12mm 1 AA
7- 4 LX-BZ0081YBE0 M Special screw 4 AA
7- 5 XOTSD40P12000 M Screw : 4mm x 12mm 4 AA
7- 6 XCBSD30P08000 M Screw : 3mm x 8mm 2 AA
7- 7 LX-CZA038WRE0 M Special screw 2 AA
7- 8 XHTSD40P08RV0 M Screw : 4mm x 8mm 3 AA
7- 9 LX-CZA070WRE0 M Special screw (Torx tamper proof screw) 2 AB
7-10 XCPSD30P08000 M Screw : 3mm x 8mm 2 AA
7-11 XOPSD40P12XS0 M Screw 3AA
