R426LS
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1 FBTN-A162WRKZ AQ Open button assembly
3-1-1 HDECQA320WRPZ AL Button decoration
3-1-2 JBTN-B379WRFZ AK Open button
3-2 FPNLCB918WRKZ BA Panel sub assy
3-2-1 PSHEPB211WREZ AT Key sheet
3-2-2 QSW-KA074DRZZ AR FPC
3-3 MSPRCA157WREZ AF Open button spring
3-4 DPWBFC558WRKZ BL Control unit
3-5 XEPS730P08XS0 AB Screw; 3mm x 8mm
DOOR PARTS
* 5-1 FDORFA412WRTZ BF Door panel
5-2 PSHEPA336WRP0 AF Sealer film
* 5-3 FWAKPA454WRKZ BE Door frame assembly
5-3-1 FBTN-A163WRKZ AS Button assy
* 5-3-2 GWAKPB063WRFZ AW Door frame
5-3-3 HDECQA321WRPZ AV Door decoration L
5-3-4 HDECQA322WRPZ AV Door decoration U
5-3-5 LSTPPA243WRFZ AG Glass stopper
5-3-6 MSPRCA160WREZ AC Button spring
5-3-7 PGLSPA680WREZ AX Door glass
5-3-8 XEPS740P08000 AB Screw : 4mm x 8mm
* 5-4 GCOVHA382WRF0 AM Choke cover
* 5-5 LSTPPA139WRF0 AE Latch head
5-6 MSPRTA084WRE0 AB Latch spring
5-7 LSTPPA167WRF0 AG Door stopper
MISCELLANEOUS
6-5 FW-VZC114WREZ AR Main wire harness
6-6 FW-VZC093WREZ AN Filter harness
6-7 TINSEB128WRRZ AM Instruction book
6-8 FW-VZC117WREZ AH Stop switch harness
